Wall Cabinets
D4
Wall Cabinets
Caution
! Installation of a wall cabinet 30˝ or wider requires additional support,
such as attachment to a soffit, or support from below.
Wall Double Door 27” H
W3027 BUTT
W3327 BUTT
W3627 BUTT
W3927
W4227
• One adjustable shelf
• Any wall cabinet over 24˝ wide or 30˝
high with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
BIS
MD
SV
MI
l
CFO
12˝
27˝
Wall Refrigerator 24” Deep 27” H
WR3627 BUTT
WR3927
• One adjustable shelf
• Designed for use over refrigerators where
there is adequate clearance
• Additional support required
When designing a built-in
refrigerator area, remember that
many side by side refrigerators
measure up to 36” wide. If you have the
extra space, it is recommended to use at
least a 1” filler with a 36” wide Wall
Refrigerator (WR) cabinet to assure clearance
for the appliance. Also, verify the height of the
appliance to make sure you are using the
correct Wall Refrigerator cabinet.
l
PE
l
APC
RD9
ID15
ID18
ID21
ID24
BIS
MD
SV
MI
l
CFO
27˝
24˝
Wall Single Door 30” H
Specify R or L
n
W930 R or L
n
W1230 R or L
W1530 R or L
W1830 R or L
W2130 R or L
W2430 R or L
• Two adjustable shelves
• Any wall cabinet over 24˝ wide or 30˝
high with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
30˝
12˝
n
Not
available with glass options (BIS, DRS.
PREP, MD, MD.PREP, SV, SV.PREP)
Wall Double Door 30” H
n
W2430 BUTT
W2730 (Butt)
n
W3030 BUTT
n
W3330 BUTT
n
W3630 BUTT
W3930
W4230
W4530
W4830
• Two adjustable shelves
• Any wall cabinet over 24˝ wide or 30˝
high with a depth greater than 12˝ and/or
with butt doors
must
be installed between
two (2) cabinets, a cabinet and a wall or
supported from below
I
Glass doors (BIS, DRS.PREP, MD, MD.PREP,
SV, SV.PREP) with Matching Interior (MI)
are available on select door styles. See
Construction Options for specifics
l
PE
l
APC
l
RD9
l
ID15
l
ID18
l
ID21
l
ID24
I
BIS
I
MD
I
SV
I
MI
l
CFO
30˝
12˝
n
Available with glass options (BIS, DRS.PREP,
MD, MD.PREP, SV, SV.PREP)
Gray color coding indicates
new product, size or code
Gray color coding indicates
new product, size or code
Gray color coding indicates
new product, size or code
