Auto-Fit™ Aluminum Hose Ends
90°
Earl’s Auto-Fit Hose Ends with nipple ends have the reliability and appear- 45°
ance of Swivel-Seal ends, but are easier to assemble, and less expensive. Straight
During assembly, the barbed nipple is pushed into the hose, securing hose between the nipple and socket, providing a tight, secure seal.
Size Straight 45° Tube 90° Tube 120° Tube 150° Tube 180° Tube
-4 EAR300104ERLP EAR304604ERLP EAR309104ERLP EAR312004ERLP EAR315004ERLP —
-6 EAR300106ERLP EAR304606ERLP EAR309106ERLP EAR312006ERLP EAR315006ERLP EAR318006ERLP
-8 EAR300108ERLP EAR304608ERLP EAR309108ERLP EAR312008ERLP EAR315008ERLP EAR318008ERLP
-10 EAR300110ERLP EAR304610ERLP EAR309110ERLP EAR312010ERLP — —
-12 EAR300112ERLP EAR304612ERLP EAR309112ERLP EAR312012ERLP — —
-16 EAR300116ERLP EAR304616ERLP EAR309116ERLP — — EAR318016ERLP

Auto-Mate Hose Ends Super Stock Hose
Auto-Mate Hose Ends are offered in traditional blue anodized or Earl’s Super Stock hose is
black Ano-Tuff hard anodized aluminum. Hose ends are compatible a blue, high quality synthetic
with Auto-Flex or Perform-O-Flex stainless steel braid protected rubber hose reinforced with an
hoses. Professional, reliable plumbing at an economical price. Re- internal braided fabric sheath.
quires auto crimp collars listed below. For use with Earl’s Super
Blue Anodized Ano-Tuff Hose Adapter Hose Stock hose ends only. Super
Part No. Part No. End Size Size Stock hose is rated at 250 PSI and 250°F and is an excellent replace-
Straight ment for original equipment applications. Should not be used with
EAR700106ERLP EARAT700106ERLP -6 -6 -6 brake fluid. On applications where maximum temperature range is
EAR700108ERLP EARAT700108ERLP -8 -8 -8 expected, compression of the Super Stock collar is required.
EAR700110ERLP EARAT700110ERLP -10 -10 -10 Hose Max. Oper. Min. Bend 10 Ft. Length 20 Ft. Length
Size I.D. O.D. Pressure Radius Part No. Part No.
EAR700112ERLP EARAT700112ERLP -12 -12 -12
-6 3/8" 5/8" 250 3" EAR791006ERL EAR792006ERL
45° -8 1/2" 3/4" 250 5" EAR791008ERL EAR792008ERL
EAR704606ERLP EARAT704606ERLP -6 -6 -6 -10 5/8" 15/16" 250 6" EAR791010ERL EAR792010ERL
EAR704608ERLP EARAT704608ERLP -8 -8 -8
EAR704610ERLP EARAT704610ERLP -10 -10 -10 Super Stock Hose Ends
EAR704612ERLP EARAT704612ERLP -12 -12 -12
90° Super Stock hose ends are an attractive, lightweight direct
replacement for the brass push-lock type. Fittings are machined
EAR709106ERLP EARAT709106ERLP -6 -6 -6 from aluminum alloy and anodized in red and blue, available in many
EAR709108ERLP EARAT709108ERLP -8 -8 -8 configurations. Use Super Stock hose ends with Earl’s Super Stock
EAR709110ERLP EARAT709110ERLP -10 -10 -10 hose (not intended for use with stainless braid pro tect ed hoses).
EAR709112ERLP EARAT709112ERLP -12 -12 -12 Hose ends are a favorite with professional racers and in limited pro-
duction stock applications. End collars may be compressed.
Auto Crimp Collars
Required for use with the above Auto-Mate Hose Ends.
Sold individually.
Hose Hose AN Fitting Hose Hose
Part No. End Size
Part No. Size No. Size
EAR798043ERLP -4 -4 Straight
EAR798063ERLP -6 -6
EAR798083ERLP -8 -8 EAR700167ERLP -6 -6 3/8"
EAR798103ERLP -10 -10 EAR700109ERLP -8 -8 1/2"
EAR798123ERLP -12 -12 EAR700111ERLP -10 -10 5/8"
EAR798163ERLP -16 -16 EAR700113ERLP -12 -12 3/4"
45°
EAR704667ERLP -6 -6 3/8"
Aluminum Tubing Adapters EAR704609ERLP -8 -8 1/2"
EAR704611ERLP -10 -10 5/8"
Adapt AN fittings to aluminum tubing.
EAR704613ERLP -12 -12 3/4"
Part No. AN Size Tube Size
90°
EAR165056ERLP -6 Male 5/16"
EAR709167ERLP -6 -6 3/8"
EAR165006ERLP -6 Male 3/8"
EAR709109ERLP -8 -8 1/2"
EAR165008ERLP -8 Male 1/2"
EAR709111ERLP -10 -10 5/8"
EAR165156ERLP -6 Female 5/16"
EAR709113ERLP -12 -12 3/4"
EAR165106ERLP -6 Female 3/8"
EAR165108ERLP -8 Female 1/2"
EAR165110ERLP -10 Female 5/8"
