Page 148 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

DMISRC-2325
Sprint Car Components (Cont.) Sprint Car Components (Cont.)
Torsion Bushings Gladiator U-Joint Assemblies
Part No. Description DMI’s assemblies are among the strongest available, each
DMISRC-2210 Bronze Torsion Bushing, .095" Tubes use large Gladiator u-joint cross which never needs grease. Available
DMISRC-2211 Bronze Torsion Bushing, .120" Tubes with full aircraft quality 7075-T6 billet aluminum or steel assembly
DMISRC-2220 Plastic Torsion Bushing, .095" Tubes with aluminum yoke.
DMISRC-2221 Plastic Torsion Bushing, .120" Tubes Part No. Description
DMISRC-2325 Aluminum U-Joint Assy., Chevy/Chrysler
Steering Arms And Pitman Arms DMISRC-2325-32 Alum. U-Joint Assy., With Gladiator Cross, 32 Spline
DMISRC-2336 Gladiator U-Joint Cross Only
Made of quality 2024 aluminum.
DMISRC-2345 Steel/Aluminum U-Joint Assy., Chevy/Chrysler
DMISRC-2353 U-Joint Bolts
DMISRC-2355 2K11 U-Joint Assy. HD, Aluminum With Gladiator Cross
DMISRC-2357 2K11 U-Joint Assy. HD, Aluminum/Steel With Gladiator Cross
DMISRC-2309
Torque Ball Housings And Collars
Part No. Description
Part No. Description DMISRC-2305 Steel Housing And Collar
DMISRC-2085 Combo Steering Arm, 5.5" x 1" Forward DMISRC-2308 New Style Housing And Collar With Insert
DMISRC-2085B Combo Steering Arm, 5.5" x 1" Forward, Black DMISRC-2309 Aluminum Hard Anodized Insert For DMISRC-2308
DMISRC-2091 Maxim Style Combo DMISRC-2311 U-Joint Spring Only
DMISRC-2091B Maxim Style Combo, Black
Single Steering Arm,
DMISRC-2100 Torque Balls
Use With DMISRC-2080 And DMISRC-2085
Single Steering Arm, Aluminum torque ball is hardcoated and then PTFE coated for a
DMISRC-2100B
Use With DMISRC-2080 And DMISRC-2085, Black “no bind” feel.
DMISRC-2101 Maxim Style Steering Arm Part Number Description
DMISRC-2101B Maxim Style Steering Arm, Black DMISRC-2370 Heavy Duty Aluminum
DMISRC-2240 Long Lightweight Pitman Arm DMISRC-2370XL Aluminum - Extra Long
DMISRC-2260 Long Lightweight Pitman Arm, Angle Broached DMISRC-2380 Lightweight Aluminum
DMISRC-2260B Long Lightweight Pitman Arm, Angle Broached, Black
DMISRC-2387B
Brake Rotors Torque Tubes
Rotors are exceptionally lightweight, but will not compromise braking.
2024-T3 aluminum tubes are first hardcoated
and then PTFE coated for a smooth, “no bind”
feel. Magnesium bases are powder coated for
corrosion resistance.
DMISRC-2393
Part No. Description
DMIRRC-2006 Torque Tube Stud Kit
DMISRC-1993 DMISRC-2701 DMISRC-2387B Big Unit XL Torque Tube, 28", Black
DMISRC-2705 DMISRC-0811 DMISRC-2710 DMISRC-2393 Torque Tube With Lightweight Magnesium Base, 28"
Part No. Description DMISRC-2393B Torque Tube With Lightweight Magnesium Base, 28", Black
DMISRC-0811 Inboard Brake Rotor, Lightened, 12" Dia., .810" Thick DMISRC-2394 Torque Tube With Lightweight Magnesium Base, 32"
DMISRC-1993 Front Rotor Bolt Kit
DMISRC-2700 Front 3-Lug Brake Rotor, Aluminum Drilled, 10-1/8" Dia. Chrome Moly And Titanium Driveshafts
DMISRC-2701 Splined Adaptor For Three Pin RR Rotor
DMISRC-2704 Front 3-Lug Brake Rotor, Steel Drilled, 10-1/4" Dia. Offers precision manufactured driveshafts in durable, 4340 chrome
DMISRC-2705 Front 3-Lug Brake Rotor, Steel Drilled, 10-3/4" Dia. moly steel or lightweight titanium. Offered in standard or big tube
DMISRC-2710 Front 3-Lug Brake Rotor, Alum. Drilled, 10-7/8" Dia. designs, driveshafts are engineered to eliminate “whip” and the as-
DMISRC-2780 Splined Right Rear Brake Rotor, Alum. Drilled, 10-1/8" Dia. sociated vibration.
DMISRC-2931 Inboard Brake Spacer
Caliper Brackets DMISRC-2445-29
Left front brackets include fasteners. DMISRC-2430
Part No. Description
DMISRC-2800 For 10-1/8" Dia. Rotor Part Number Description
DMISRC-2800B For 10-1/8" Dia. Rotor, Black Chrome Moly Steel Driveshafts
DMISRC-2810 For 10-7/8" Dia. Rotor DMISRC-2481 26-1/2" Swivel Driveshaft
DMISRC-2810B For 10-7/8" Dia. Rotor, Black DMISRC-2442-29 29" Swivel Driveshaft WP With Ball
DMISRC-2442-29-32 29" Swivel Driveshaft WP With Ball, 32-Spline
DMISRC-2430 30" Standard Driveshaft
Splined Inboard Rotor Mounts DMISRC-2430-32 30" Driveshaft, 32-Spline
Billet aluminum rotor mounts. DMISRC-2431-32 31" Driveshaft, 32-Spline
DMISRC-2440 32" Standard Driveshaft
Big Tube Driveshafts
DMISRC-2446-26.5 26-1/2" Big Tube Driveshaft, Swivel Coupler
DMISRC-2445-29 28-3/4" Big Tube Driveshaft, Internal Coupler, XR1 & XR2
DMISRC-2934 DMISRC-2446-29.25 29-1/4" Big Tube Driveshaft, Swivel Coupler
DMISRC-2932 Titanium Driveshaft
DMISRC-2930
Part No. Description DMISRC-2441-29 29" Swivel Driveshaft WP With Ball
DMISRC-2930 One-Piece Floater Style Replacement Component
DMISRC-2932 Clamp Style, Hard Anodized DMISRC-2444 Ball For WP Style Driveshaft
DMISRC-2934 Tri-Lock Inboard Brake Clamp
147
