Beam Coping Machine G Code

Voortman's commitment and dedication to support and service is legendary. They are the industry's standard. Voortman employs a global team to support customers. They are always available at the Voortman 24-hour customer support center. Voortman offers support via a world-class remote diagnostic tool, available local support and a warranty that is unmatched in the industry.

Although we prefer the machine to be installed indoors, there are several Voortman beam copier installations outside. The machine and control panel must have adequate weather protection. For photos of many of our outdoor installations, please contact us.

Plasma heads are very popular for cutting steel, due to the high quality and speed of the cuts. However, due to the size of the plasma cutting head it is not possible to get the head close enough to the flange, and many styles of copes typically required in beams are just not possible with plasma heads.

Voortman inside technicians are often able to resolve any problem remotely. Voortman technicians can access your machine via an internet connection. Voortman equipment has a powerful Windows(r-based Siemens control which allows this capability and offers superior diagnostics through Windows(r).

Voortman can do almost all kinds of structural steel fabrication. From shaping beams, plate to coping relieves and custom profiles. The CNC beam coping machines can be used to replace drill lines and band saws as well as layout and marking stations. Voortman is only one-man-operable. Voortman is a better choice for quality work, quicker turnarounds, and less waste.

The triple torch design of the ABCM-1250 CNC beam coping machine allows for the cutting of two flanges simultaneously. While flange thins are performed on both top and bottom flanges at the same time, weld prep is generated concurrently, keeping operating costs at a minimum. Without tedious torch probing processes, the ABCM-1250 oxy-fuel coper allows for more near flange cutting.

AKYAPAK offers an innovative solution for the steel construction sector again... High speed and high processing performances with AFDs up to 1000x1500 mm (44"x60") materials.

Programming of the CNC Beam Coping Machine is very simple even when done manually. The machine programming software is Peddimat and most operators can learn how to program most parts in less than an hour. Of course practice makes perfect. However the best way to program the machine is to import parts directly from a CAD drawing preferably done in some 3-D modeling software such as Tekla Structures, SDS/2, ProSteel 3D, StruMis etc. These files import directly into the machine. In some cases the operator might need to edit the part program to create a lead out to ensure smooth cutting and then he merely selects the part to be processed and hits the Cycle Start button.
