Molding
Note
: Heavy, dark lines indicate finished surfaces.
Decorative Enhancements
Classic Crown Molding
CCM8 •NG
CCM10 •NG
• Solid wood
• Foil-wrapped MDF supplied for White Laminate
• Painted hardwood supplied for EverCore™, Cream
Laminate and 10’ molding
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Quartersawn door styles will be supplied in plain
sawn wood
• Will have rustic characteristics when ordered in
rustic door styles.
Use
caution
when applying Classic
Crown Molding (CCM8), Crown
Molding (CM8), etc., when ”stair stepping” wall
cabinets in full overlay door styles otherwise the
doors may hit the molding while opening.
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
2
7
/
16
˝
3
5
/
16
˝
4
1
/
8
˝
3
/
4
˝
8´,10´
Classic Crown Molding w/Molding Mounting Strip
CCM8 •MS
CCM10 •MS
• Solid wood
• Painted hardwood supplied for EverCore™
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Quartersawn door styles will be supplied in plain
sawn wood
• Will have rustic characteristics when ordered in
rustic door styles.
• Mounting strip may be installed first, allowing
for easier alignment and quicker installation of
grooved moldings
• Shipped as two pieces
v
A
v
B
v
C
v
E
v
H
L
LHG
v
LWG
v
M
v
O
v
QS
3
5
/
16
˝
2
7
/
16
˝
4
1
/
8
˝
3
/
4
˝
1 ¼˝
¾˝
8´,10´
Sterling Crown Molding
Large
LSTCM8
Extra Large
XLSTCM8
• Solid wood
• Painted hardwood supplied for EverCore™ and
Laminate
I
Painted hardwood supplied for Woodgrain
Laminate door styles; only available in white
The Sterling Collection design combines
automated wood-machining processes
with hand detailing. Because of the
hand detailing, slight imperfection and/or
differences may exist from part to part and are
normal. These do
not
affect the structural
performance of the product but enhance the
aesthetics of each piece.
v
A
B
v
C
v
E
H
v
L
LHG
I
LWG
v
M
O
QS
8´
8´
2 ½˝
2 / ˝
4 ½˝
LSTCM
XLSTCM
3 / ˝
Cove Molding
Small
SCVM8 •NG
SCVM10 •NG
Large
LCVM8 •NG
LCVM10 •NG
Extra Large
XLCVM8 •NG
XLCVM10 •NG
• Solid wood
• Painted hardwood supplied for EverCore™, Cream
Laminate and 10’ molding, except for Small Cove
Molding (SCVM8) and Large Cove Molding
(LCVM8), which will have foil-wrapped MDF
supplied for White Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Quartersawn door styles will be supplied in plain
sawn wood
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
2˝
1
8´,10´
SCVM •NG
2
2
8´,10´
LCVM •NG
3 / ˝
4
XLCVM •NG
½˝
½˝
/ ˝
8´,10´
/ ˝
