Decorative Enhancements
Angle Crown Molding
ACM8
ACM10
Extra Large
XLACM8
XLACM10
• Solid wood
• Angle Crown Molding (ACM) has foil-
wrapped MDF and Extra Large Angle Crown
Molding (XLACM) has painted hardwood
supplied for White Laminate
• Painted hardwood supplied for EverCore™,
Cream Laminate and 10’ molding
• Plain sawn material supplied for Burnaby
Crafted door styles
• Will have rustic characteristics when ordered
in rustic door styles.
• The mounting cleat is finished but is
not
a
matching wood species to the face
• The mounting cleat is
not
intended to be exposed after
installation
2˝
131°
8´,10´
8´,10´
2 / ˝
4 / ˝
/ ˝
/ ˝
1 / ˝
2 / ˝
2¾˝
¾˝
XLACM
ACM
33°
/ ˝ 2 / ˝
1˝
2 / ˝
2 / ˝
2 / ˝
4½˝
Angle Crown Molding–Face-Mount
ACM8 •FM
ACM10 •FM
Extra Large
XLACM8 •FM
XLACM10 •FM
• Solid wood
• Painted hardwood supplied for EverCore™
and Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Will have rustic characteristics when ordered
in rustic door styles.
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
2 / ˝
1 / ˝
2¾˝
/ ˝
41°
8´,10´
4
2 / ˝
/ ˝
½˝
ACM •FM
XLACM •FM
8´,10´
33°
Soffit Crown Molding
SCM8
SCM10
• Solid wood
• Foil-wrapped MDF supplied for White
Laminate
• Painted hardwood supplied for EverCore™,
Cream Laminate and 10’ molding
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Quartersawn door styles will be supplied in
plain sawn wood
Remember to account for miter
cuts and returns when choosing the
amount of molding needed for a
job.
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
1
1
/
8
˝
1
1
/
8
˝
8´,10´
Crown Molding
CM8 •NG
CM10 •NG
Large
LCM8 •NG
LCM10 •NG
• Solid wood
• Crown Molding (CM8) has foil wrapped
MDF supplied for laminates and painted
hardwood supplied for EverCore™
• Large Crown Molding (LCM8 and LCM10)
and Crown Molding (CM10) is painted
hardwood supplied for EverCore™ and Cream
Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Quartersawn door styles will be supplied in
plain sawn wood
• Will have rustic characteristics when ordered
in rustic door styles.
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
8´,10´
8´,10´
2 / ˝
2 / ˝
1 / ˝
1 / ˝
CM •NG
LCM •NG
Crown Molding w/Molding Mounting Strip
CM8 •MS
CM10 •MS
Large
LCM8 •MS
LCM10 •MS
• Solid wood
• Painted hardwood supplied for EverCore™
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Quartersawn door styles will be supplied in
plain sawn wood
• Will have rustic characteristics when ordered
in rustic door styles.
• Mounting strip may be installed first,
allowing for easier alignment and quicker
installation of grooved moldings
• Shipped as two pieces
v
A
v
B
v
C
v
E
v
H
L
LHG
v
LWG
v
M
v
O
v
QS
1
1 ¼˝
¾˝
¾˝
2 / ˝
8´,10´
/ ˝
1 / ˝
CM •MS
LCM •MS
8´,10´
1 ¼˝
2 / ˝
