Decorative Enhancements
Inset Light Rail
ILR8
• Solid wood
• Allows application of 3/4˝ inserts
• Painted hardwood supplied for EverCore™
and Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Quartersawn door styles will be supplied in
plain sawn wood
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
8´
5
/
8
˝
1
3
/
8
˝
3
/
4
˝
1
13
/
16
˝
Mission Light Rail
MLR8
• Solid wood
• Painted hardwood supplied for EverCore™
and Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Groove accepts LED tape lighting
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
8´
¾˝
1
½
˝
2˝
Sterling Light Rail
STLR8
• Solid wood
• Painted hardwood supplied for EverCore™
and Laminate
I
Painted hardwood supplied for Woodgrain
Laminate door styles; only available in white
• Groove accepts LED tape lighting
The Sterling Collection design
combines automated wood-
machining processes with hand
detailing. Because of the hand
detailing, slight imperfection and/or
differences may exist from part to part and
are normal. These do
not
affect the structural
performance of the product but enhance the aesthetics of
each piece.
v
A
B
v
C
v
E
H
v
L
LHG
I
LWG
v
M
O
QS
8´
/ ˝
1
/ ˝
1 / ˝
Batten Molding
BM8
Narrow
NBM8
• Solid wood
• Painted hardwood supplied for EverCore™
and Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Quartersawn door styles will be supplied in
plain sawn wood
v
A
v
B
v
C
v
E
v
H
v
L
LHG
v
LWG
v
M
v
O
v
QS
8´
8´
1 / ˝
¼˝
¾˝
BM
NBM
¼˝
Mission Batten Molding
MBM8
• Solid wood
• Painted hardwood supplied for EverCore™
• Plain sawn material supplied for Burnaby
Crafted Cherry and Maple door styles.
Quartersawn Oak supplied for Burnaby
Crafted Oak door styles
I
Painted hardwood supplied for Woodgrain
Laminate door styles; only available in white
v
A
B
v
C
v
E
H
L
LHG
I
LWG
v
M
O
v
QS
8´
3
/
8
˝
1
3
/
8
˝
