299 / 601
F10
Tall Cabinets
Note
: Remember to remove the white plastic “feet” from the bottom of all tall cabinets before
installation. Their sole purpose is to protect the floor after the cabinets are unboxed. Leaving them on
will result in uneven installation.
Tall Cabinets
Tall Pantry Pull-out
Specify R or L
84” High
i
TPP92484 R or L
TPP122484 R or L
TPP152484 R or L
87” High
i
TPP92487 R or L
TPP122487 R or L
TPP152487 R or L
90” High
i
TPP92490 R or L
TPP122490 R or L
TPP152490 R or L
93” High
TPP92493 R or L
TPP122493 R or L
TPP152493 R or L
96” High
i
TPP92496 R or L
TPP122496 R or L
TPP152496 R or L
• Two fixed shelves attached to center and
bottom of bottom door
• Two adjustable shelves
• Pull-out shelves are 21 3/4” deep
• Includes adjustable shelves in upper section:
84” & 87” high—one shelf; 90” & 93” high—
two shelves; 96” high—three shelves
• Unit slides on full extension side-mount
runners
• Toe kick is shipped separately on 93˝ & 96˝
high cabinets
I
WR
not
available on 93˝ & 96˝ high cabinets
I
Void Toe Kick (VTK) is
not
available on 93”
and 96” high cabinets
• No center rail on tall door for Adrian, Burnaby, Captiva,
Carter, Castlewood, Coleburne, Edgemont, Edgemont
Cathedral, Fielding, Grange, Hailey, Holace, Jackson,
Jasper, Kensie, Lennox Court, Lessex, Madison, Maris,
Newburgh, Parkdale, Standish, Stanford, Summit,
Torrington and Veranda door styles
Remember to order a 3/16” skin (WSK) for the
exposed ends of 93” & 96” high cabinets to
conceal the seam between the loose toe kick
and the cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
RD
ID
IF
I
WR
l
XS
GD
RTK
I
VTK
24˝
10 ½˝
9 / ˝
9 / ˝
14 / ˝
4 ½˝, 7 ½˝, 10 ½˝
Shelf Width
84˝
87˝
90˝
93˝
96˝
23 ½˝
27˝
30˝
33˝
36˝
i
Doors are square except full overlay arch door
styles. Laminate door styles will always be
square. Huntley, Scarbourough and Veranda
doors will have a solid, recessed flat panel.
Tall Pantry Pull-out 60 1/2” H
i
TPP92460
TPP122460
TPP152460
• Two fixed shelves attached to center and
bottom of door
• Two adjustable shelves
• Pull-out shelves are 21 3/4” deep
• Unit slides on full extension side-mount
runners
• All door styles furnished square
• No center rail on tall door for Adrian,
Burnaby, Captiva, Carter, Castlewood,
Coleburne, Edgemont, Edgemont Cathedral,
Fielding, Grange, Hailey, Holace, Jackson,
Jasper, Kensie, Lennox Court, Lessex,
Madison, Maris, Newburgh, Parkdale,
Standish, Stanford, Summit, Torrington and
Veranda door styles
l
PE
l
APC
l
APFC
l
FPEB
MI
l
DE
OE
RD
ID
IF
l
WR
l
XS
GD
RTK
l
VTK
24˝
60
1
/
2
˝
23 ½˝
23 / ˝
4 ½˝, 7 ½˝, 10 ½˝
Shelf Width
i
Huntley, Scarbourough, Veranda doors will
have a solid, recessed flat panel
