135
°
12 / ˝
16 / ˝
16 /
˝
12 / ˝, 18 / ˝, 24 / ˝
35 / ˝, 41 / ˝, 47 / ˝
BIEC36-48
47 / "
24 / "
16 / "
16 / "
12 / "
135
°
BIEC48 BUTT
E36
Base Island
Base Cabinets
Island End Cabinet
Specify R or L
BIEC36 R or L
BIEC42 R or L
BIEC48 R or L
BIEC48 BUTT
• One adjustable shelf
•
Must
get all doors with glass when glass
option is chosen
Remember, when designing with a
BIEC36, the center door is 12”
(nominal). Since several door
inserts are
not
available on doors narrower
than 18” wide, please consult the
specifications for your desired glass option. If
you require glass on just the right and left
door, you can order replacement doors for
those positions with a glass option
l
PE
l
APC
APFC
l
MI
DE
IF
TWR
l
GD
v
RTK
l
VTK
Base Decorative End Cabinet
Specify R or L
Classic Leg
BDEC181534 R or L•CLS
BDEC241534 R or L•CLS
BDEC182434 R or L•CLS
BDEC242434 R or L•CLS
Plain Square Post
BDEC181534 R or L•PSP
BDEC241534 R or L•PSP
BDEC182434 R or L•PSP
BDEC242434 R or L•PSP
Roman Spindle
BDEC181534 R or L•RSP
BDEC241534 R or L•RSP
BDEC182434 R or L•RSP
BDEC242434 R or L•RSP
Sterling Leg
BDEC181534 R or L•STL
BDEC241534 R or L•STL
BDEC182434 R or L•STL
BDEC242434 R or L•STL
Tapered Leg
BDEC181534 R or L•TPL
BDEC241534 R or L•TPL
BDEC182434 R or L•TPL
BDEC242434 R or L•TPL
• Available in Alder–Rustic, Cherry, EverCore™,
Laminate and Maple and full overlay door
styles only
• Laminates are painted hardwood
• Side doors are fully operational
• Sides and backs are finished both sides
• When Beaded (BEB) or V-Groove (VGRB)
Back options are selected, the opposite side
will be finished plain wood veneer
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Open area height from top of bottom shelf to
cabinet frame is 16”
PE
APC
v
APFC
v
MI
DE
IF
TWR
GD
RTK
VTK
BDEC182434L•CLS shown
CLS
34 ½˝
RSP
34 ½˝
PSP
34 ½˝
TPL
34 ½˝
STL
34 ½˝
34½˝
15
24
¾˝
¾˝
18
24
¾˝
¾˝
