E31
Peninsula Base Corner Cabinets
Base Cabinets
Peninsula Easy Reach Wood Super Susan
Specify R or L Rear Frame Position
Iu
PEZR33 RR or L•WSS
Iu
PEZR33 LR or L•WSS
i
PEZR36 RR or L•WSS
i
PEZR36 LR or L•WSS
• Two pie-cut shelves rotate individually
• EZR33 has 28˝ diameter shelves; EZR36 has
32˝ diameter shelves
• Rotating shelves are attached to cabinet floor
and fixed shelf
• Shelves rotate independently
• Lazy Susan
cannot
be turned from peninsula
side with kitchen side doors in closed
position
• Frame opening, from left to right edge is
10 1/2˝ for EZR33 and 14 3/4˝ for EZR36
• Doors are profiled on one long and two short
edges and are connected with hinges
• The first R or L designates kitchen side door
hinging
• The second R or L designates rear (peninsula)
frame position
• Butt doors on peninsula side
• 31˝ door clearance recommended for delivery
• Toe kick is detachable
•
Note:
Kitchen side does
not
include Soft-Close
feature. Peninsula side doors feature Soft-Close
hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
IF
TWR
WR
l
XS
I
GD
RTK
v
RTKP
VTK
34
1
/
2
˝
24˝
33˝, 36˝
33˝, 36˝
33 / ˝
6 / ˝, 8 / ˝
33
36
33˝, 36˝
24˝
All dimensions are to
outside of frame
I
Glass doors
not
available on kitchen side
u
Hathaway, Southington and Vienna doors will
have a solid, recessed flat panel on kitchen
side. Carrington doors will have a veneer,
recessed flat panel on kitchen side.
i
Not
available with Aluminum Frame glass
doors on kitchen side
Peninsula Base Angle Cabinet
Specify R or L Rear Frame Position
PBA36 RR or L
PBA36 LR or L
• One fixed shelf
• Full-height doors
• Toe kick is detachable
• The first R or L designates kitchen side door
hinging
• The second R or L designates rear (peninsula)
frame position
• 31˝ door clearance recommended for
delivery
•
Note:
Full Overlay door styles: Kitchen
side (front) doors use a 1/2” overlay hinge.
Peninsula side (back) doors use a full overlay
hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
IF
TWR
WR
XS
l
GD
RTK
v
RTKP
VTK
34
1
/
2
˝
24˝
36˝
36˝
42 / ˝
36˝
36˝
24˝
