34
1
/
2
˝
24˝
24˝
17˝
29¾˝
24˝
36˝
36˝
18˝
24˝
17˝
All dimensions are to
outside of frame
34
1
/
2
˝
36˝
19½˝
36˝
24˝
20 / ˝
8¼˝
All dimensions are to
outside of frame
34
1
/
2
˝
36˝
19½˝
36˝
24˝
20 / ˝
8¼˝
All dimensions are to
outside of frame
E26
Base Corner Cabinets
Base Cabinets
Wood Lazy Susan
Specify R or L
LS36 R or L•WLS
• Rotating shelves have plywood floor and
solid wood trim
• Shelves rotate independently
• Requires 36” of wall space
• Face frame is scooped for hinge installation
on full overlay door styles
• Doors are profiled on one long and two short
edges and are connected with hinges
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
I
Back (barrel) will
not
be plywood when APC
is chosen
PE
I
APC
APFC
FPEB
MI
DE
RD
TWR
l
WR
l
XS
l
GD
RTK
RTKP
VTK
Base Corner Fixed Shelf
Specify R or L
BCFS36 R or L
• One fixed shelf
• Requires 36” of wall space
• Face frame is scooped for hinge installation
on full overlay door styles
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
I
Back (barrel) will
not
be plywood when APC
is chosen
•
Note:
Does
not
include Soft-Close feature
PE
I
APC
APFC
FPEB
MI
DE
RD
TWR
l
WR
l
XS
GD
RTK
RTKP
VTK
Lazy Susan End Panel
Specify R or L
LSEP •R or L
• Notched to fit behind stile of Lazy Susan
front frame
• Requires 3/16” of wall space
• Quartersawn door styles will be supplied in
plain sawn wood
• Painted hardwood supplied for EverCore™
• Exterior finished to match, interior is Natural
Birch Viraguard
l
PE
l
APC
l
APFC
l
FPEB
MI
DE
RD
TWR
WR
XS
GD
RTK
RTKP
VTK
1
/
2
˝
1
/
2
˝
3
/
16
˝
5
/
16
˝
Base Angle
Specify R or L
BA36 R or L
• One fixed shelf
• False drawer front
• Angled back provides clearance for
installation
• 30 1/2˝ door clearance recommended for
delivery
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
RD
l
TWR
l
WR
XS
l
GD
l
RTK
RTKP
l
VTK
