E35
Base Island
Base Cabinets
Base Island
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
MI
Matching Interior
DE Integrated Decorative End
IF
Inverted Frame
TWR Top Wide Rail
GD Glass Doors
RTK Recessed Toe Kick
VTK Void Toe Kick
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
CBT 36 24 • CL • VT
code width depth leg style suffix
Floating Island Base
FIB24 BUTT
i
FIB30
FIB30 BUTT
i
FIB36
FIB36 BUTT
i
FIB36 •2D
Void Top
FIB24 BUTT•VT
i
FIB30 •VT
FIB30 BUTT•VT
i
FIB36 •VT
FIB36 BUTT•VT
i
FIB36 •2D•VT
• Top surface is 1 1/2˝ thick Maple chopping
block and extends 1˝ beyond cabinet—
not
including doors and drawers
• Cutting Board Finish (CBF) is recommended
for top; see Touch-up section of this book
• One adjustable shelf
• Drawer and runners are reduced 3” in depth
from standard
• One standard full-width Roll-out Tray (ROT)
• Deluxe Roll-out Tray (DXROT) option
not
available;
not
to be field installed
• Back is matching wood veneer or laminate
• Outside Corner Molding at back corners
• Void Top (VT) option allows for field installation of a
decorative top
• Field applied top
not
to exceed 100 lbs.
•
Not
available in Morrisbrook; Durham and Meredith
supplied plain sawn
•
Note:
Top shipped separately
Note:
It is recommended
not
to exceed 100
lbs. when applying a customer supplied top
on Floating Island Base cabinets.
PE
v
APC
APFC
l
MI
l
DE
IF
l
TWR
l
GD
RTK
VTK
36˝
24˝
i
A mullion strip is attached to the left door
Peninsula Floating Island Base
PFIB24 BUTT
i
PFIB30
PFIB30 BUTT
i
PFIB36
PFIB36 BUTT
i
PFIB36 •2D
Void Top
PFIB24 BUTT•VT
i
PFIB30 •VT
PFIB30 BUTT•VT
i
PFIB36 •VT
PFIB36 BUTT•VT
i
PFIB36 •2D•VT
• Top surface is 1 1/2˝ thick Maple chopping
block and extends 1˝ beyond cabinet—
not
including doors and drawers
• Cutting Board Finish (CBF) is recommended
for top; see Touch-up section of this book
• One adjustable shelf
• Drawer and runners are reduced 3” in depth
from standard
• False drawer front on peninsula side
• Deluxe Roll-out Tray (DXROT) option
not
available;
not
to be field installed
• Void Top (VT) option allows for field installation of a
decorative top
• Field applied top
not
to exceed 100 lbs.
•
Not
available in Morrisbrook; Durham and Meredith
supplied plain sawn
•
Note:
Top shipped separately
PE
v
APC
l
APFC
l
MI
l
DE
IF
l
TWR
l
GD
RTK
VTK
36˝
24˝
i
A mullion strip is attached to the left door
