E33
Base End Run Cabinets
Base Cabinets
Base Z-Angle
Specify R or L
BZA12 R or L
• Right shown
• Two adjustable shelves
• One optional tray divider available in center location only
•
Not
available in Laminate, High-Gloss Laminate or
Woodgrain Laminate door styles
• Contrasting Back Options (CBEB, CPLB, CVGR)
not
available
• Doors will
not
receive pegs when ordered in Mission Oak
& Hickory; Morrisbrook Oak and Lynchburg Cherry door
styles
• Outside profile will contain eased edges and will
not
match straight doors for Bartlett Cherry & Maple door
styles
•
Not
available in Burwell, Durham Oak, Fox Ridge Roman (Half &
Full), Fox Ridge Square (Half & Full), Frederickton, Gresham, Hartwell,
Hathaway, Jamestown, Jayden, Kendall, Lowell, Salem, Southington,
Templeton, & Vienna
I
Minimum Reduced Depth (RD) is 12˝
I
Recessed Toe Kick (RTK) available hinge side only
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
I
RD
WR
GD
I
RTK
RTKP
l
VTK
34
1
/
2
˝
24˝
12˝
18˝
18˝
12˝
24˝
3˝
8
1
/
2
˝
3˝
Base Message Center
Specify R or L
MCB24 R or L
• For use at the end of a cabinet run
• Includes cork board and two magazine racks
• Filler Overlay (FO) supplied, ships separately, field install
PE
APC
v
APFC
FPEB
MI
DE
RD
l
WR
l
GD
v
RTK
RTKP
l
VTK
4 / ˝
34 ½˝
New
Grey color coding indicates
new product, size or code.
Base End Open Shelf 24” Deep
Specify R or L
BEOS624 R or L
BEOS924 R or L
BEOS1224 R or L
• 5/8” wood veneer construction
• 1 3/16˝ thick bottom shelf
• Three fixed shelves
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB, CVGR)
not
available
• For Curved Moldings, see Molding section in Decorative
Enhancements
• Painted hardwood supplied for EverCore™
• Plain sawn material supplied for Burwell Crafted door
styles
•
Not
available in High-Gloss Laminate or Woodgrain
Laminate door styles
•
Not
available in Morrisbrook; Durham and Meredith supplied
quartersawn
I
Reduced Depth (RD) available in 3” increments to a minimum of
12”
• Order Example: BEOS1224R-RD reduce depth to 18˝
PE
l
APC
APFC
FPEB
v
MI
DE
I
RD
WR
GD
RTK
RTKP
l
VTK
Left shown
34 ½˝
24˝
9 / ˝
9 / ˝
11 / ˝
9 / ˝
24˝
6˝
R
24˝
9˝
4¾˝
4¾˝
R
24˝
12˝
R
Solid Wood Base End Open Shelf 24” Deep
Specify R or L
SBEOS624 R or L
SBEOS924 R or L
SBEOS1224 R or L
• Three fixed shelves
• 1 3/16˝ thick bottom shelf
• Solid wood construction on shelves only
• 5/8˝ wood veneer on sides and back
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB, CVGR)
not
available
• Painted hardwood supplied for EverCore™ and Laminate
• Plain sawn material supplied for Burwell Crafted door
styles
• For Curved Moldings, see Molding section in Decorative
Enhancements
•
Not
available in High-Gloss Laminate or Woodgrain
Laminate door styles
•
Not
available in Morrisbrook; Durham and Meredith supplied
quartersawn
I
Shelves remain solid when APC option is chosen; sides and back will
be 11/16˝ matching wood veneer plywood
I
Reduced Depth (RD) available in 3” increments to a minimum of 12”
• Order Example: SBEOS 1224R-RD reduce depth to 18˝
PE
I
APC
APFC
FPEB
v
MI
DE
I
RD
WR
GD
RTK
RTKP
l
VTK
Left shown
24˝
24˝
6˝
R
24˝
9˝
R
24˝
12˝
R
34 ½˝
9 / ˝
9 / ˝
11 / ˝
9 / ˝
4¾˝
4¾˝
