12˝
Front view
1 / ˝
12 / ˝
16 / ˝
48˝
54˝
57˝
60˝
Side view
Lift mechanism
10 / ˝
8 / ˝
12˝
12˝
25 ½˝
24˝
24˝
17˝
12˝
Front view
1 / ˝
12 / ˝
16 / ˝
48˝
54˝
57˝
60˝
Side view
Lift mechanism
10 / ˝
8 / ˝
12˝
12˝
25 ½˝
24˝
24˝
17˝
D17
Wall Corner Cabinets
Wall Cabinets
Wall Angle Appliance Garage Chrome Lazy Susan
Specify R or L
Two shelves
48” High
WAAG2448 R or L•CLS
Three shelves
54” High
WAAG2454 R or L•CLS
57” High
WAAG2457 R or L•CLS
60” High
WAAG2460 R or L•CLS
• 19 11/16” diameter rotating shelves
• Shelves rotate together
• Clearance from countertop to
bottom of door is 20 1/32˝
• Adjustable Soft-Close lift
mechanism standard
• Bottom door is always square
• Void All Door and Drawer Front
option (VDA) is
not
available
I
Glass doors available for top doors
only
•
Note:
Full overlay door styles use
a 1/2” overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
RD
ID
TWR
XS
XSG
I
GD
New
Gray color coding indicates new product, size or code.
Wall Angle Appliance Garage Wood Lazy Susan
Specify R or L
Two shelves
48” High
WAAG2448 R or L•WLS
Three shelves
54” High
WAAG2454 R or L•WLS
57” High
WAAG2457 R or L•WLS
60” High
WAAG2460 R or L•WLS
• 19 1/2” diameter rotating shelves
• Shelves rotate independently
• Adjustable Soft-Close lift
mechanism standard
• Rotating shelves have plywood
floor and solid wood trim
• Clearance from countertop to
bottom of door is 20 1/32˝
• Bottom door is always square
• Void All Door and Drawer Front
option (VDA) is
not
available
I
Glass doors available for top doors only
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
RD
ID
TWR
XS
XSG
I
GD
Wall Easy Reach
Specify R or L
Two shelves
30” High
i=n
WEZR2130 R or L
WEZR2430 R or L
33” High
i=n
WEZR2133 R or L
WEZR2433 R or L
Three shelves
36” High
i=n
WEZR2136 R or L
s
WEZR2436 R or L
39” High
i=n
WEZR2139 R or L
WEZR2439 R or L
42” High
i=n
WEZR2142 R or L
WEZR2442 R or L
• Right shown
• Adjustable shelves
• Frame opening from left to right
edge:
10 1/2˝ for WEZR21
14 3/4˝ for WEZR24
• Face frame is scooped for hinge
installation on full overlay door
styles
• Hinged door opens to 170°
I
Not
available with Aluminum
Frame Glass doors
•
Note:
Does
not
include Soft-Close feature
Do
not
design a corner cabinet
adjacent to an object deeper than
the end panel. The door of the
corner cabinet may
not
function properly.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
OE
RD
ID
TWR
l
XS
XSG
I
GD
30˝
33˝
36˝
39˝
42˝
12˝
21˝, 24˝
21˝, 24˝
16 / ˝
12˝
21˝,24˝
21˝
24˝
12˝
i
Doors are square except full overlay arch door styles.
Laminate doors styles will always be square. Hathaway
Cherry & Maple, Southington Cherry & Maple and
Vienna Cherry & Maple doors will have a solid,
recessed flat panel. Carrington doors will have a veneer,
recessed flat panel
=
Glass door option
not
available
n
Woodgrain Laminate door styles will be supplied as
vertical grain slabs
s
1 3/4˝ face frame
