30˝
24˝
12˝
13 ½˝
opening
25 / ˝
24˝
24˝
12˝
12˝
D20
Peninsula Wall Corner Cabinets
Wall Cabinets
Peninsula Wall Angle Wood Lazy Susan
Specify R or L Kitchen Side Hinging
Specify R or L Rear Frame Position
Two Shelves
PWA2430 RR or RL•WLS
PWA2430 LR or LL•WLS
• Left/Left shown
• 19 1/2” diameter rotating shelves
• Shelves rotate independently
• Rotating shelves have plywood floor and
solid wood trim
• Butt doors on peninsula side
• Frame backs are
not
finished
• See example for hinging and rear door position
•
Note:
Full Overlay door styles: Kitchen side (front)
doors use a 1/2” overlay hinge. Peninsula side (back)
doors use a full overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
ID
XS
l
GD
Peninsula Wall Easy Reach
Specify R or L Kitchen Side Hinging
Specify R or L Rear Frame Placement
Two shelves
30” High
PWEZR2430 RR or RL
PWEZR2430 LR or LL
33” High
PWEZR2433 RR or RL
PWEZR2433 LR or LL
Three shelves
36” High
PWEZR2436 RR or RL
PWEZR2436 LR or LL
39” High
PWEZR2439 RR or RL
PWEZR2439 LR or LL
42” High
PWEZR2442 RR or RL
PWEZR2442 LR or LL
• Right/Left shown
• Adjustable shelves
• Butt doors on peninsula side
• Hinged door opens to 170°
• See example for hinging and rear door
position
• Frame backs are
not
finished
I
Not
available with Aluminum Frame glass doors on
kitchen side
•
Note:
Kitchen side does
not
include Soft-Close feature.
Peninsula side doors feature Soft-Close hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
ID
l
XS
I
GD
24˝
24˝
30˝
33˝
36˝
39˝
42˝
12˝
24˝
14 / ˝
23 / ˝
12˝
12˝
