24˝
24˝
30˝
18˝
48˝
12˝
13 ½˝
12˝
12˝
25 ½˝
24˝
24˝
17˝
48˝
24˝
24˝
30˝
12˝
18˝
13 ½˝
opening
12˝
12˝
25 ½˝
24˝
24˝
17˝
48˝
24˝, 27˝
24˝, 27˝
30˝
12˝, 15˝
18˝
15˝
27˝
27˝
15˝
17˝
29 ¼˝
WA24
WA27
12˝
12˝
25 ½˝
24˝
24˝
17˝
D14
Wall Corner Cabinets
Wall Cabinets
Wall Angle Tambour Chrome Lazy Susan
Specify R or L
Two shelves
WAT2448 R or L•CLS
• 19 11/16” diameter rotating shelves
• Shelves rotate together
• Tambour opens to allow 13 1/2” access
height
• Tambour tension controlled with thumb
screw adjustment
•
Not
available in Woodgrain Laminate door
styles
•
Not
available in Morrisbrook; Durham and
Meredith supplied plain sawn on pull and
tambour door
•
Note:
Full overlay door styles use a 1/2” overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
RD
ID
TWR
XS
XSG
l
GD
New
Gray color coding indicates new product, size or code.
Wall Angle Tambour Wood Lazy Susan
Specify R or L
Two shelves
WAT2448 R or L•WLS
• 19 1/2” diameter rotating shelves
• Shelves rotate independently
• Rotating shelves have plywood floor and
solid wood trim
• Tambour opens to allow 13 1/2” access
height
• Tambour tension controlled with thumb
screw adjustment
•
Not
available in Woodgrain Laminate door
styles
•
Not
available in Morrisbrook; Durham and
Meredith supplied plain sawn on pull and tambour
door
•
Note:
Full overlay door styles use a 1/2” overlay hinge
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
OE
RD
ID
TWR
XS
XSG
l
GD
Wall Angle Drawer
Specify R or L
WAD2448 R or L
I
WAD2748 R or L
• Three drawers with full extension side-mount
runners
• Top drawer will be slab, including DRPD,
except Deveron, Lynchburg and Provence
door styles which will be five-piece
• If DRPD option is selected, the bottom two
drawer fronts will be five-piece recessed
panel for Woodvale Roman and Woodvale
Square
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
l
PE
l
APC
l
APFC
I
FPEB
l
MI
DE
OE
RD
ID
TWR
XS
XSG
l
GD
I
Furniture Plywood Ends (FPEB) standard;
recommended Matching Interior option is
MIFP
