D9
Wall Corner Cabinets
Wall Cabinets
Wall Blind Corner 23 1/2”—42” H
Specify R or L
One shelf
Single Door
23 1/2” High
WBC2724 R or L
WBC3024 R or L
WBC3324 R or L
WBC3624 R or L
WBC3924 R or L
Two shelves
30” High
i;
WBC2430 R or L
WBC2730 R or L
WBC3030 R or L
WBC3330 R or L
WBC3630 R or L
WBC3930 R or L
33” High
i;
WBC2433 R or L
WBC2733 R or L
WBC3033 R or L
WBC3333 R or L
WBC3633 R or L
WBC3933 R or L
• R or L indicates blind
• Adjustable shelves
• Overlay Panel for Wall Blind Corner
Cabinet (OPWBC) is recommended
for full overlay door styles and
must
be ordered separately; see
Base Accessories Section of this
book
Remember to order Flush
Finished Blind (FFB) on a
Wall Blind Corner (WBC)
if the adjacent cabinet is shorter than the
WBC.
Any wall cabinet over 24˝ wide or
30˝ high or higher with a depth
greater than 12˝ and/or with butt
doors
must
be installed between two (2)
cabinets, a cabinet and a wall or supported
from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
l
RD
I
ID
I
TWR
l
XS
XSG
I
GD
23 ½˝
30˝
33˝
12˝
8˝
23 ½˝
30˝
12˝
8˝
WBC2724-WBC3933
WBC2436-WBC3942
WBC4224-WBC4830
36˝
39˝
42˝
12˝
8˝
Left shown
i
Doors are square except full overlay arch door styles.
Laminate doors styles will always be square. Hathaway,
Southington and Vienna doors will have a solid,
recessed flat panel
;
Glass door option
not
available
u
Top Wide Rail (TWR) option
not
available
I
Not
available in Increased Depth (ID)
s
Two butt doors
Wall Blind Corner 48˝ and 54˝ H
Specify R or L
Three shelves
48” High
i;
WBC2448 R or L
WBC2748 R or L
WBC3048 R or L
WBC3348 R or L
WBC3648 R or L
I
WBC3948 R or L
Specify R or L
Four shelves
54” High
i;
WBC2454 R or L
WBC2754 R or L
WBC3054 R or L
WBC3354 R or L
WBC3654 R or L
I
WBC3954 R or L
• R or L indicates blind
• Adjustable shelves
• Shelves shipped separately
• Available in full overlay door styles
only
• Overlay Panel for Wall Blind Corner
Cabinet (OPWBC) is recommended
for full overlay door styles and
must
be ordered separately; see
Base Accessories Section of this
book
I
Maximum Increased Depth (ID) is 15˝
I
Not
available with Camed glass door (GD)
option
I
Not
available with Mullion glass doors (GD)
option
I
Modern Frosted (MRT) and Moire (MOI)
Glass Inserts
not
available on 54˝ H cabinets
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
OE
l
RD
I
ID
TWR
l
XS
XSG
I
GD
48˝
54˝
12˝
8˝
Left shown
i
Doors are square except full overlay arch door styles.
Laminate doors styles will always be square. Hathaway,
Southington and Vienna doors will have a solid,
recessed flat panel
;
Glass door option
not
available
I
Not
available in Increased Depth (ID)
Three shelves
36” High
i;
WBC2436 R or L
WBC2736 R or L
WBC3036 R or L
WBC3336 R or L
WBC3636 R or L
39” High
i;u
WBC2439 R or L
u
WBC2739 R or L
u
WBC3039 R or L
u
WBC3339 R or L
u
WBC3639 R or L
u
WBC3939 R or L
42” High
i;u
WBC2442 R or L
u
WBC2742 R or L
u
WBC3042 R or L
u
WBC3342 R or L
u
WBC3642 R or L
u
WBC3942 R or L
Double Door
One shelf
23 1/2” High
Is
WBC4224 R or L
I
WBC4524 R or L
I
WBC4824 R or L
Two shelves
30” High
Is
WBC4230 R or L
I
WBC4530 R or L
I
WBC4830 R or L
