Panels-Shelving-Trays
K1
Decorative Appliance Panels
Decorative
Appliance Panels
Construction Options and
Modifications
Material dimensions may vary slightly
based on lumber industry standards.
Specifications subject to change
without notice.
APDW
code
Decorative Appliance Panel–Pricing Method
• General Pricing Rules:
• Using the outer most dimension of each panel, the width and height should be converted into a decimal form.
Examples: 21 9/16˝ = 21.5625; 58 7/16˝ = 58.4375, etc.
• Calculated dimensions will be rounded using the standard rounding method (down from 4 and up from 5) to the nearest 10,000th place.
Example: 8.7504069 will round to 8.7504.
• List prices will be rounded up to the nearest dollar from .01 cents. Example: $179.01 will become $180.
• Please use the following instructions to determine the LIST PRICE of each panel, remembering to use the rounding method mentioned above.
• Start by taking the panel width and height, in decimal form, and multiply the two numbers together giving you the total square inches.
Example: (21 9/16˝) 21.5625 x (58 3/8˝) 58.4375 = 1260.058594 sq. in., which rounds to 1260.0586 sq. in.
• Next, you need to convert square inches into square feet by taking the square inch figure and dividing that number by 144.
Example: 1260.0586 ÷ 144 = 8.7504069 sq. ft., which rounds to 8.7504 sq. ft.
• Next, multiply the total square feet by the appropriate square foot list price to get the total list price.
Example 8.7504 x $128 = 1120.05, which rounds to $1121 list price.
•
Note:
Prices shown above are merely examples and are
not
actual list prices
Decorative Panel–Back Panel
APWSK
• Approximately 3/16˝ thick
• Back Panels will match the wood species and
the color of the selected door style and finish
and can be used with or without onlay panels
to decorate any appliance
• Wood veneer engineered wood
•
Not
available in EverCore™ or High-Gloss
Laminate door styles
• Finished one side only
• Quartersawn door styles are quartersawn
wood veneer
• Quartersawn Cherry and Maple door styles
supplied plain sawn
• Edges are unfinished with no edgebanding
Back Panel
Minimum Width 4 ½˝
Maximum Width 48˝
Minimum Height
¾˝
Maximum Height
96˝
