Passport Cabinets
J5
Passport Cabinets
Passport cabinetry is available in 1/2” overlay door styles only.
Passport Peninsula Base Blind Corner
APBBC27
• One adjustable shelf
• For use as a starter cabinet for peninsula
• Two 5 1/2” stiles on blind side allow cabinet to be used
as right or left
• Reversible
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
IF
TWR
l
XS
l
GD
RTK
APBBC27
Peninsula
Base Cabinet
5 ½˝ Stiles
Base
Cabinet
32 ½˝
27˝
24˝
24˝
27˝
Passport Peninsula Base Blind Corner w/Pull-out
APBBC36 R or L•BPP
• Requires a minimum of 39” wall space
• Blind panel (stile) is 6” wide
•
Must
be pulled min. 12”, max. 15”
• Pull-out Heights:
Top shelf—8 1/4”
Bottom shelf—7 3/4”
• Right blind shown
• Filler included
• Unit slides on heavy duty full extension runners with
integrated buffer
•
Note
: If using decorative hardware on adjacent cabinets, allow at
least 40” wall space to allow for clearance of pull-out unit
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
IF
TWR
l
XS
GD
RTK
32 ½˝
24˝
Passport Lazy Susan
ALS36
• Two pie-cut, 28” diameter, interior Viraguard rotating
shelves
• Requires 36” of wall space
• Doors are attached to and rotate with the Lazy Susan
• Contrasting Back Options (CBEB, CPLB, CVGR)
not
available
PE
l
APC
APFC
FPEB
MI
RD
IF
TWR
l
XS
GD
RTK
32 ½˝
Passport Base End Corner
ABEC24
• One fixed shelf
• Can be installed on either right or left end
• Contrasting Back Options (CBEB, CPLB, CVGR)
not
available
l
PE
l
APC
APFC
FPEB
l
MI
RD
IF
TWR
XS
l
GD
RTK
32 ½˝
24˝
24˝
24˝
67.5°
135°
24˝
23¾˝
18 / ˝
Passport Base End Open Shelf
Specify R or L
ABEOS1224 R or L
• One fixed shelf
• 5/8” wood veneer construction
• Painted hardwood supplied for EverCore™
• 11 5/8” radius
• 1 3/16˝ thick bottom shelf
• Toe kick is finished
• Left shown
• For Curved Moldings, see Molding section of this book
I
Reduced Depth (RD) available in 3” increments to a
minimum of 12”
PE
l
APC
APFC
FPEB
v
MI
I
RD
IF
TWR
XS
GD
RTK
12
˝
24˝
12˝
11 / ˝ R
11 / ˝
10 ¼˝
32 ½˝
24˝
