Passport cabinetry is available in 1/2” overlay door styles only.
Passport Sink Front
ASF30
ASF36
• Includes floor; shipped loose
• UTK
not
available
• Unit is
not
trimmable
• Includes a Touch-Up Kit (TUK)
PE
l
APC
APFC
FPEB
MI
RD
IF
TWR
l
XS
l
GD
RTK
32 ½˝
Passport Plumbing Skirt and Sink Collar Usage
ASRB
ABSR
24˝
12˝
27˝
34˝
5 ½˝
1 ½˝
Side view
For proper fit, install WSK or VSK on base
and tall cabinets next to ABSR
Top view
12˝
24˝
Passport Base Microwave
Opening Width
ABMW21
18”
ABMW24
21”
ABMW27
24”
• One standard drawer
• Opening height 14”
• Designed for countertop style microwaves
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
IF
TWR
l
XS
GD
l
RTK
32 ½˝
24˝
Passport Base Dishwasher Cabinet
ABDW27
• Allows for 11” raised installation of standard
dishwashers
• Finished top required
• Plywood floor
• False drawer front
l
PE
l
APC
l
APFC
l
FPEB
MI
RD
IF
TWR
l
XS
GD
RTK
46 ½˝
24˝
27˝
Passport Base Blind Corner w/Pull-out
Specify R or L Blind
ABBC36 R or L•BPP
• Requires a minimum of 39” wall space
• Blind panel (stile) is 6” wide
•
Must
be pulled min. 12”, max. 15”
• Pull-out Heights:
Top shelf—8 1/4”
Bottom shelf—7 3/4”
• Right blind shown
• Filler included
• Unit slides on heavy duty full extension
runners with integrated buffer
•
Note
: If using decorative hardware on adjacent cabinets,
allow at least 40” wall space to allow for clearance of
pull-out unit
l
PE
l
APC
l
APFC
l
FPEB
l
MI
RD
IF
TWR
l
XS
GD
l
RTK
32 ½˝
24˝
27˝
