Passport Cabinets
J6
Passport Cabinets
Passport cabinetry is available in 1/2” overlay door styles only.
Passport Solid Wood Base End Open Shelf
Specify R or L
ASBEOS1224 R or L
• One fixed shelf
• 5/8˝ wood veneer on sides and back
• 1 3/16˝ thick bottom shelf
• 11 5/8” radius
• Solid wood construction on shelves only
• Painted hardwood supplied for EverCore™
• Toe kick is finished
• Left shown
• For Curved Moldings, see Molding section of this book
I
Shelves remain solid when APC option is chosen; sides
and back will be 11/16˝ matching wood veneer plywood
I
Reduced Depth (RD) available in 3” increments to a minimum of 12”
PE
I
APC
APFC
FPEB
v
MI
I
RD
IF
TWR
XS
GD
RTK
12
˝
24˝
12˝
11 / ˝ R
32 ½˝
24˝
11 / ˝
10 ¼˝
Passport Peninsula Base End Open Shelf
APBEOS2412
• Two fixed shelves
• 5/8˝ wood veneer construction; back is 11/16˝ when APC
option is chosen
• 1 3/16˝ thick top and bottom shelves
• 11 5/8” radius
• Painted hardwood supplied for EverCore™
• Toe kick is finished
• Back may be notched in field for continuous toe kick
applications
• For Curved Moldings, see Molding section of this book
PE
l
APC
APFC
FPEB
v
MI
RD
IF
TWR
XS
GD
RTK
24˝
32 ½˝
10 ¼˝
10 ¼˝
12 / ˝
24˝
Passport Peninsula Solid Wood Base End Open Shelf
ASPBEOS2412
• Two fixed shelves
• 5/8˝ wood veneer on back panel
• 1 3/16˝ thick top and bottom shelves
• 11 5/8” radius
• Solid wood construction on shelves only
• Painted hardwood supplied for EverCore™
• Toe kick is finished
• Back may be notched in field for continuous toe kick
applications
• For Curved Moldings, see Molding section of this book
I
Shelves remain solid when APC option is chosen; back will be 11/16˝
matching wood veneer plywood
PE
I
APC
APFC
FPEB
v
MI
RD
IF
TWR
XS
GD
RTK
24˝
32 ½˝
10 ¼˝
10 ¼˝
12 / ˝
24˝
Passport Base Pull-out Table
ABDT24
• One standard drawer
• One deep drawer
• Top constructed of laminated Maple melamine
• Load capacity 160 lbs.
•
Not
for use as a freestanding cabinet.
Must
be secured to
floor or wall.
•
Not
designed to be used as a cutting board
l
PE
l
APC
l
APFC
l
FPEB
MI
RD
IF
TWR
l
XS
GD
l
RTK
24˝
30˝
32 ½˝
Passport Base Tambour
ABTS18
ABTS21
ABTS24
ABTS30
• One standard drawer
• Tambour is solid wood
• Painted hardwood supplied for EverCore™
• Tambour tension controlled with thumb screw
adjustment
• Opening height 12 1/2”
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
IF
TWR
l
XS
GD
l
RTK
24˝
32 ½˝
