Wall Cabinets
D62
Wall Hoods
Wall Hood Box Straight Valance
21” High
WHB301821 •ST
WHB361821 •ST
WHB362121 •ST
WHB422121 •ST
26 1/2” High
WHB301827 •ST
WHB361827 •ST
WHB362127 •ST
WHB422127 •ST
33” High
WHB301833 •ST
WHB361833 •ST
WHB362133 •ST
WHB422133 •ST
39” High
WHB301839 •ST
WHB361839 •ST
WHB362139 •ST
WHB422139 •ST
• Solid wood/wood veneer construction
• Laminates are painted hardwood
• All door styles will default to full overlay
• Doors are attached by false front clips.
Not
operational
• Designed to align with top of adjacent
cabinets
• Valance adds 3” to overall height and 5/32”
width to both sides
• Valances will be supplied in plain-sawn
material for Quartersawn Cherry and
Quartersawn Maple door styles
• Includes (2) Wall Hood Box Fillers, shipped separately
• 30 5/16” and 36 5/16” wide hoods have a single door
panel
• 42 5/16” wide hoods have three door panels
• 19” deep requires component package “J”
• 22” deep requires component package “G” or “P”
• Check local building codes for required clearances
between the Wall Hood and cooking surface
• Filler strips are used when butting adjacent cabinets
against the Wall Hood Box. Fillers
must
be used in this
application to avoid gaps between cabinet boxes.
•
Not
available in Belmont Roman, Belmont Square, Hanley
Roman, Hanley Square or Harper door styles
•
Note
: Square doors will be supplied when ordered in
arched door styles
•
Note
: Cabinetry and appliances located below these Wall
Hoods
must
be pulled to a minimum of 27˝deep and a
maximum of 30˝ deep for improved function
The Wall Hood Box Filler should be used when
installing the hood box between two wall
cabinets
PE
APC
v
APFC
FPEB
MI
DE
CW
RD
ID
CH
XS
XSG
GD
WHB361827.ST
WHB421827.ST
21
˝
26
½˝
33
˝
39
˝
21
˝
26
½˝
33
˝
39
˝
42
/ ˝
30
/ ˝
36
/ ˝
19
˝
22
˝
22
˝
Radius to match top of valance
Wall Hood Box Filler
36
˝
¾˝
/ ˝
Wall Hood Matching Straight Valance
23 1/2” High
WHMSV3624
WHMSV4224
WHMSV4824
WHMSV5424
30” High
WHMSV3630
WHMSV4230
WHMSV4830
WHMSV5430
• Solid wood/wood veneer construction
• 23 1/2˝ high units are designed to align with
90˝ cabinets
• 30˝ high hoods are designed to align with
96˝ high cabinets
• Will accept optional onlays, ordered
separately; see Molding Accents section of
this book
• Check local building codes for required
clearances between the Wall Hood and
cooking surface
• Requires component package “G”
• Doors open to facilitate duct installation and wiring
• Laminates are painted hardwood
•
Not
available in Morristown; Brockton, Melrose and
Putnam Oak supplied plain sawn
•
Note
: Wall Hood
must
be installed between two cabinets
•
Note
: Cabinetry and appliances located below these Wall
Hoods
must
be pulled to a minimum of 27˝deep and a
maximum of 30˝ deep for improved function
PE
v
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
XS
XSG
GD
WHMSV 36
12˝
23˝
18˝
open
18˝
23
1
/
2
˝
30˝
WHMSV 42- 54
12˝
12˝
15˝
16
1
/
2
˝
18˝
18˝
21˝
12˝
15˝
16
1
/
2
˝
open
2
1
/
4
˝
2
19
/
64
˝
6
1
/
4
˝
6
3
/
16
˝
23
1
/
2
˝
30˝
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth Floor Opening
Width
Floor Opening
Depth
WHMSV36
33 ⅛˝
10 ⁄
˝
34 ⅝˝
21 ⁄
˝
29 ⅛˝
17˝
WHMSV42
39 ⅛˝
10 ⁄
˝
40 ⅝˝
21 ⁄
˝
29 ⅛˝
17˝
WHMSV48
45 ⅛˝
10 ⁄
˝
46 ⅝˝
21 ⁄
˝
29 ⅛˝
17˝
WHMSV54
51 ⅛˝
10 ⁄
˝
52 ⅝˝
21 ⁄
˝
29 ⅛˝
17˝
