Wall Cabinets
D58
Wall Hoods
Peninsula Wall Hood Classic Chimney Flat Panel Valance
Plain
32” High
PWHCCFPV302832 •P
PWHCCFPV363332 •P
PWHCCFPV423332 •P
44” High
PWHCCFPV302844 •P
PWHCCFPV363344 •P
PWHCCFPV423344 •P
PWHCCFPV302856 •P
56” High
PWHCCFPV363356 •P
PWHCCFPV423356 •P
• Solid wood/wood veneer
construction
• Check local building codes for
required clearances between the
Wall Hood and cooking surface
• A 3˝ space is recommended on
the right and left side of this unit
before beginning the adjacent
cabinet runs
• 32˝ high hoods are designed for
use with 8 foot ceilings
• 44˝ high hoods are designed for
use with 9 ft. ceilings
• 56˝ high hoods are designed for use with
10 ft. ceilings
• Decorative molding matches Soffit Crown
Molding profile (SCM8)
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™ and
Laminate
•
Not
available in Morristown; Brockton, Melrose
and Putnam Oak supplied plain sawn
• 30˝ wide requires component package “K”
• 36˝–42˝ wide requires component package “H”
or “O”
•
Note
: Cabinetry and appliances located below
these Wall Hoods
must
be pulled to a minimum
of 27˝deep and a maximum of 30˝ deep for
improved function
•
Note
: Wall hood
must
be securely anchored to
ceiling
PE
v
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
PWHCCFPV30
7 ⁄
˝
6 ⁄
˝
28 ⅝˝
24 ½˝
PWHCCFPV36
14 ½˝
10 ½˝
34 ⅝˝
28 ½˝
PWHCCFPV42
20 ½˝
10 ½˝
40 ⅝˝
28 ½˝
PWHCCFPV•P
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
32˝
44˝
56˝
11
15
/
16
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
32˝
44˝
56˝
11
15
/
16
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
PWHCCFPV•BE
Unless indicated, measurements include molding
Wall Hood Classic Artisan Chimney
30 5/8” High
WHCC301930 •A
WHCC361930 •A
WHCC362430 •A
WHCC422430 •A
42 5/8” High
WHCC301942 •A
WHCC361942 •A
WHCC362442 •A
WHCC422442 •A
54 5/8” High
WHCC301954 •A
WHCC361954 •A
WHCC362454 •A
WHCC422454 •A
• Solid wood/wood veneer construction
• Check local building codes for
required clearances between the
Wall Hood and cooking surface
• Will accept optional onlays,
ordered separately; see Molding
Accents section of this book
• A 3˝ space is recommended on
the right and left side of this unit
before beginning the adjacent
cabinet runs
• 30 5/8˝ high hoods are designed
for use with 8 foot ceilings
• 42 5/8˝ high hoods are designed
for use with 9 ft. ceilings
• 54 5/8˝ high hoods are designed
for use with 10 ft. ceilings
• Shaded areas are unfinished surfaces that allow
for field application of paint or other decorative
material
• Lower molding matches Beaded Panel Molding
(BPM8) profile, other molding matches Soffit
Crown Molding profile (SCM8)
• This product will
not
be covered under warranty
once alterations of any kind have been made
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™ and
Laminate
•
Not
available in Morristown; Brockton, Melrose
and Putnam Oak supplied plain sawn
• 19˝ deep requires component package “J”
• 24˝ deep requires component package “G” or “P”
•
Note
: Cabinetry and appliances located below
these Wall Hoods
must
be pulled to a minimum
of 27˝deep and a maximum of 30˝ deep for
improved function
•
Note
: Wall Hood
must
be securely anchored to
wall
Select a Wall Hood Classic Artisan
Chimney when your design requires a
customer specified finish treatment
such as tile, stucco, metal or paint. The
chimney and angled sections of the hood are
unfinished to allow paint or other adhesives to
hold more securely. The valance and molding
section will match the wood and finish of your
chosen door style.
PE
v
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
WHCC30•A
8˝
7 ⁄
˝
28 ½˝
18 ⁄
˝
WHCC36•A
14 ⁄
˝
10 ¾˝
34 ½˝
21 ⁄
˝
WHCC42•A
20 ½˝
10 ¾˝
40 ½˝
21 ⁄
˝
20
3
/
16
˝
23
7
/
16
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
3
/
4
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
6
5
/
16
˝
8˝, 20˝, 32˝
22
5
/
8
˝
30
5
/
8
˝
42
5
/
8
˝
54
5
/
8
˝
WHCC•A
Unless indicated, measurements include molding.
Shaded areas are unfinished.
Beaded Panel
32” High
PWHCCFPV302832 •BE
PWHCCFPV363332 •BE
PWHCCFPV423332 •BE
44” High
PWHCCFPV302844 •BE
PWHCCFPV363344 •BE
PWHCCFPV423344 •BE
56” High
PWHCCFPV302856 •BE
PWHCCFPV363356 •BE
PWHCCFPV423356 •BE
