Wall Cabinets
D52
Wall Microwave Cabinets
Wall Microwave Cabinet w/Drawer–Extended Opening
No shelves in upper section
48” High
WMCDE272148 (Butt)
WMCDE302148
WMCDE272448 (Butt)
WMCDE302448
One shelf in upper section
54” High
WMCDE272154 (Butt)
WMCDE302154
WMCDE272454 (Butt)
WMCDE302454
Two shelves in upper section
60” High
WMCDE272160 (Butt)
WMCDE302160
WMCDE272460 (Butt)
WMCDE302460
• One deep drawer
• Designed for “built-in” style microwaves
•
Not
intended as a wall mounted cabinet; unit
must
be supported by another cabinet or
countertop
l
PE
l
APC
l
APFC
l
FPEB
l
MI
CW
l
RD
ID
CH
l
XS
l
GD
48˝
54˝
60˝
21˝, 24˝
11˝
15˝
18˝
24˝
Cabinet
Min
Width
Max.
Width
Min.
Height
Max.
Height
WMCD27_48 16˝
25˝
15˝ 18 1/2˝
WMCD27_54 16˝
25˝ 15 1/2˝ 19˝
WMCD27_60 16˝
25˝
15˝ 18 1/2˝
WMCD30_48 19˝
28˝
15˝ 18 1/2˝
WMCD30_54 19˝
28˝ 15 1/2˝ 19˝
WMCD30_60 19˝
28˝
15˝ 18 1/2˝
Cut out dimensions
Wall Microwave Box
18” High
Opening trimmable to:
Width: 16” to 25”
Height: 11” to 15 1/2”
WMB271818
WMB272118
Opening trimmable to:
Width: 19” to 28”
Height: 11” to 15 1/2”
WMB301818
WMB302118
21” High
Opening trimmable to:
Width: 16” to 25”
Height: 14” to 18 1/2”
WMB271821
WMB272121
WMB272421
Opening trimmable to:
Width: 19” to 28”
Height: 14” to 18 1/2”
WMB301821
WMB302121
WMB302421
23 1/2” High
Opening trimmable to:
Width: 16” to 25”
Height: 17” to 21 1/2”
WMB272124
WMB272424
Opening trimmable to:
Width: 19” to 28”
Height: 17” to 21 1/2”
WMB302124
WMB302424
• Designed for “built-in” style microwaves
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Back Options (BEB and VGRB)
not
available
• Painted hardwood supplied for EverCore™
•
Note
:
Must
be installed between two
cabinets or cabinet and wall with supplied
connectors
l
PE
l
APC
l
APFC
l
FPEB
MI
CW
l
RD
ID
CH
XS
GD
18˝
21˝
18˝, 21˝,24˝
23
½
˝
