Wall Cabinets
D60
Wall Hoods
Peninsula Wall Hood Classic Chimney Raised Panel Valance
Plain
32” High
PWHCCRPV302832 •P
PWHCCRPV363332 •P
PWHCCRPV423332 •P
44” High
PWHCCRPV302844 •P
PWHCCRPV363344 •P
PWHCCRPV423344 •P
56” High
PWHCCRPV302856 •P
PWHCCRPV363356 •P
PWHCCRPV423356 •P
• Solid wood/wood veneer
construction
• Check local building codes for
required clearances between the
Wall Hood and cooking surface
• A 3˝ space is recommended on
the right and left side of this unit
before beginning the adjacent
cabinet runs
• 32˝ high hoods are designed for
use with 8 foot ceilings
• Decorative molding matches Soffit
Crown Molding profile (SCM8)
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™ and
Laminate
•
Not
available in Morristown; Brockton, Melrose
and Putnam Oak supplied plain sawn
• 30˝ wide requires component package “K”
• 36˝–42˝ wide requires component package
“H” or “O”
•
Note
: Cabinetry and appliances located below
these Wall Hoods
must
be pulled to a minimum
of 27˝deep and a maximum of 30˝ deep for
improved function
•
Note
: Wall hood
must
be securely anchored to
ceiling
PE
v
APC
APFC
FPEB
MI
DE
CW
RD
ID
CH
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
PWHCCRPV30
7 ⁄
˝
6 ⁄
˝
28 ⅝˝
24 ½˝
PWHCCRPV36
14 ½˝
10 ½˝
34 ⅝˝
28 ½˝
PWHCCRPV42
20 ½˝
10 ½˝
40 ⅝˝
28 ½˝
WHCCRPV•P
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
15
/
16
˝, 15˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
15
/
16
˝, 15˝
PWHCCRPV•BE
Unless indicated, measurements include molding
Wall Hood Box
18” High
WHB301818
WHB361818
WHB362118
WHB422118
23 1/2” High
WHB301824
WHB361824
WHB362124
WHB422124
30” High
WHB301830
WHB361830
WHB362130
WHB422130
36” High
WHB301836
WHB361836
WHB362136
WHB422136
• Solid wood/wood veneer
construction
• Laminates are painted hardwood
• All door styles will default to full
overlay
• Doors are attached by false front
clips.
Not
operational
• Designed to align with top of
adjacent cabinets
• 30” and 36” wide hoods have a
single door panel
• 42” wide hoods have three door panels
• 19” deep requires component package “J”
• 22” deep requires component package “G” or “P”
• Check local building codes for required
clearances between the Wall Hood and cooking
surface
• The 18” high Wall Hood Box will require a soffit
or a molding box application to house the duct
work for the blower unit
•
Not
available in Belmont Roman, Belmont
Square, Hanley Roman, Hanley Square or Harper
door styles
•
Note
: Square doors will be supplied when
ordered in arched door styles
•
Note
: Cabinetry and appliances located below
these Wall Hoods
must
be pulled to a minimum
of 27˝deep and a maximum of 30˝ deep for
improved function
PE
APC
v
APFC
FPEB
MI
DE
CW
RD
ID
CH
XS
XSG
GD
WHB361824
18˝
23
½˝
30˝
36˝
18˝
23
½˝
30˝
36˝
19˝, 22˝
30˝, 36˝
42˝
22˝
WHB422124
Beaded Panel
32” High
PWHCCRPV302832 •BE
PWHCCRPV363332 •BE
PWHCCRPV423332 •BE
44” High
PWHCCRPV302844 •BE
PWHCCRPV363344 •BE
PWHCCRPV423344 •BE
56” High
PWHCCRPV302856 •BE
PWHCCRPV363356 •BE
PWHCCRPV423356 •BE
