Page 111 - 2018 Racecar Engineering Late-Model Muscle Car Parts and Accessories Catalog

PowerMAX Plus
Mastertorque Starters
Original Look Starters
PowerMAX Original Look High output Mastertorque starters offer 180 ft./
Although they look virtually identical to the
Starters lbs. of torque, sufficient power to handle engines
OEM starter, PowerMAX Plus Starters offer
Looks virtually identical to the OEM start- increased cranking power and added durabil- with up to 14.0:1 compression ratios. Infi-Clock
er, yet provides 160 ft./lbs. of high-torque ity. Starters use a 1.4kw, 1.7 HP motor and 6:1 design allows mounting starter as desired for
cranking power through use of a special, gear reduction to deliver 160 ft./lbs. of cranking maximum header or oil pan clearance.
heavy duty electric motor and starter drive. power. Part No. Description
Part No. Description Part No. Description PWM9600 1993-02 Camaro V8
PWM9202 1993-02 Camaro LT1, ZZ4 PWM9100 1993-02 Camaro V8 PWM9609 2010-16 Camaro V8
PWM9201 2010-16 Camaro V8 168 Tooth PWM9004-9 2010-16 Camaro V8

High-Amp Alternators
Modern, high performance muscle cars with
XS Torque Starters Ultra Torque Starters audio/video equipment, navigation systems,
Capable of starting engines with up to Starters live up to their name with 250+ ft./ aftermarket lights and other electrical compo-
18.0:1 compression ratios, extra powerful lbs. of torque. Starters are compatible with nents require the need for a high-amp alternator.
XS Torque starter delivers up to 200 ft./ most kickout oil pans and feature an adjustable Each high-amp alternator features hand-wound,
lbs. of torque through use of a 4.4:1 gear aluminum mounting block for maximum oil pan/ custom-designed stators, heavy duty rectifiers
reduction design. Infi-Clock feature allows header clearance. Heavy duty, 2.5 kW, 3.4 HP and regulators, and gold-plated battery post for
maximizing header and oil pan clearance. motor provides superior durability. reliable, long-lasting performance. Natural finish.
Part No. Description Part No. Description Part No. Description
PWM9502 1993-02 Camaro V8 PWM9400 1993-02 Camaro V8 PWM48237 1998-02 Camaro V8, 220 amp
PWM9509 2010-16 Camaro V8 PWM9409 2010-16 Camaro V8 PWM47805 1993-97 Camaro V8, 220 amp
PWM41487 2010-15 Camaro 6.2L, w/2-Pin Decoupler, 220 amp

Integrated Coil PFM141-257
Brackets
Coil Relocation l R l i LS Slant Edge Covers
Unique rail mounting
system attaches to the Extension Cords These new valve covers are taller than
valve covers, and the indi- Necessary when relocating LS ignition stock valve covers and can accommodate
vidual coils simply attach coils somewhere out of sight. Includes a wide variety of large valve train applica-
to the rail. All necessary authentic Delphi connectors and is built tions. Fits GM LS engines only.
hardware included. and tested to withstand life in the engine Part No. Description
compartment. Sold as individual cords. PFM141-261 Chevy Orange, Raised Emblem
Part No. Description
PFM69520* Coil Bracket For LS 1 Style Coils Part No. Description PFM141-262 Black Crinkle, Raised Emblem
PFM69521* Coil Bracket For LS 3 And 7 Style Coils PFM69525 18" Extension Cord PFM141-263 Cast Gray, Raised Emblem
* MSD 39849 13"-15" longer spark plug wires are needed PFM69526 46" Extension Cord PFM141-264 Polished, Recessed Red/Black Emblem
PFM141-265
Chromed, Recessed Red/Black Emblem
PFM141-266 Polished, No Emblem
PFM141-256 Black Crinkle, Ralie LSX Emblem

Cylinder Head Valve Cover Mounting Bolts PFM66330
Mounting bolts are necessary to mount Chevrolet and Bowtie LS valve covers part
numbers 141-257, and 141-261 thru 141-266 to LSX-DR cylinder Heads.

110 CAMARO PRODUCTS
