Page 107 - 2018 Racecar Engineering Late-Model Muscle Car Parts and Accessories Catalog

Camaro Ring And Pinion Sets
Heavy duty, standard weight ring and pinion sets are made of 8620 steel and heat treated for strength and durability.
Available Differential Master Bearing Kit includes Timken carrier and pinion bearings, cover gasket, crush sleeve,
marking compound and brush, pinion nut, pinion seal, ring gear bolts, pinion and carrier shims, and thread locking
compound.
Part No. Description
7.5"
MOTG875342 Camaro 1993-02, 3.42 Ratio
MOTG875373 Camaro 1993-02, 3.73 Ratio
MOTG875390 Camaro 1993-02, 3.90 Ratio
MOTG875410 Camaro 1993-02, 4.10 Ratio
MOTG875456 Camaro 1993-02, 4.56 Ratio
7.5" Style Installation Kits
MOTR7.5GRMK Camaro 1993-98
MOTR7.5GRLMK Camaro 1999-02
8.6" IRS
MOTG886391 Camaro 2010-17, 3.91 Ratio
8.6” Differential Master Bearing Kit
MOTR8.6RMKT Camaro 2010-17 NEW!
Note: 3.23 & numerically higher carrier only

MULTIPLE SPARK DISCHARGE
MSD8381
Digital 6A And 6AL Ignition Controls
MSD kept the same footprint as the traditional 6AL but lowered
the profile for a sleek look. The wiring is all routed out one end of
the unit through a sealed and locking connector, easing installa- MSD8226 MSD8733
tion and keeping the wiring neat and clean. The rev limiter was
moved right on top of the housing for easy access to the two
rotary dials to set the limit in 100 rpm increments.
Inside the Digital 6ALis a microprocessor that monitors and
controls every firing and rev limit, and the ignition produces more
power while drawing less current!
The new Digital 6A and 6AL are supplied with the wiring
harness and the components for installation. The 6AL is also
supplied with vibration mounts. Both ignitions are compatible on MSD6014
MSD6014
4, 6 or 8-cylinder engines with 12-volt, negative ground electrical
systems. Compatible with breaker points, amplifiers and mag-
netic pickups. Camaro Ignition Components
Part No. Description MSD offers a wide variety of ignition components for popular Camaros.
MSD6201 Digital 6A ™ Ignition Control, No Rev Limiter Part No. Description
MSD6425 Digital 6AL ™ Ignition Control, With Soft Touch Rev Control 1993-97 Camaro LT1 V8
MSD8226 1993-95, Replacement Coil - Dual Connector
MSD8231 1996-97, Replacement Coil - SingleConnector
MSD8381 1993-94, Pro-Billet Distributor - Early Model Spline Driven
MSD83811 1994-97, Pro-Billet Distributor - Late Model Pin Driven
MSD8481 1993-94, Replacement Distributor Cap/Rotor Kit - Early Model
MSD84811 1994-97, Replacement Distributor Cap/Rotor Kit - Late Model
MSD8876 1993-95, Wiring Harness To Install MSD6201/6425
MSD8877 1996-97, Wiring Harness To Install MSD6201/6425
MSD32143 1993-97, Direct Fit Spark Plug Wire Set - Black
MSD32149 1993-97, Direct Fit Spark Plug Wire Set - Red
1998-02 Camaro LS1 V8
Pro Power Coils For GM LS2/LS7 NEW!C il F GM LS2/LS7 MSD6014 1998-02, 6LS Ignition Controller
Pro Power ignition coils deliver increased spark energy and MSD8215 1998-02, Coil Brackets For OEM Or MSD Coils
voltage to the spark plugs, improving the combustion process MSD8886 1998-02, EFI Wire Harness To Install MSD6010
and performance. Sold each or in sets of eight, coils bolt directly MSD32813 1998-02, Direct Fit Spark Plug Wire Set - Black
MSD32819
1998-02, Direct Fit Spark Plug Wire Set - Red
in place. MSD82858 1998-02, Direct Fit Coils - Set of 8 (VIN #G)
Part No. Description MSD88867 1998-02, Direct Fit Power Upgrade Coil Wire Harness
MSD82878 2010-15 Camaro, Pro Power Coil, 8-Pack 2010-15 Camaro LS V8
MSD8287 2010-15 Camaro, Pro Power Coil, Each MSD8733 Camaro 2010-15, Two Step Rev Limiter
MSD82858 1998-02 Camaro, Pro Power Coil, 8-Pack MSD6014 Camaro 2010-15, 6LS Ignition Controller Red
MSD8285 1998-02 Camaro, Pro Power Coil, Each MSD60143 Camaro 2010-15, 6LS Ignition Controller Black

106 CAMARO PRODUCTS
