Page 114 - 2018 Racecar Engineering Late-Model Muscle Car Parts and Accessories Catalog

Street Hydraulic
Release Bearing RAM78180
Designed for use with aftermarket perfor-
Force 9.5 and 10.5 mance clutches in applications where the
factory throwout bearing mechanism will
Twin-Plate Clutch Systems
not handle the abuse of high performance
Ram Force 9.5 and 10.5 dual disc clutches
HDX and Powergrip Clutch Sets racing clutch. For use with a hydraulic
are ideal for street and race use. The high clutch master cylinder in high performance
RAM HDX clutch sets feature increased clamp loads torque capacity of these twin plate clutches can
and a high performance street organic disc. Discs handle most blower applications. The strapped street and drag race applications.
are built with the exclusive 8-spring hub and poly coil floater plate eliminates rattle at idle. The top Part No. Description
RAM78180
2010-14 Camaro V8
springs for excellent strength and durability. HDX set clutch disc features a sprung hub that absorbs RAM78165 1998-02 Camaro
provides the smoothest engagement for street driven the initial engagement and reduces the chance
cars. Powergrip set includes the same increased of chatter at release. The Force 9.5 is suited for Hydraulic
clampload pressure plates with a 900/300 series fric- applications up to 750 HP(800 ft/lbs TQ), while
tion material for an excellent balance between drive- the 10.5 (950 ft/lbs TQ) is for applications up to System
ability and holding power up to 550 hp at the wheels 1000 HP. Compatible with factory master cyl- Adjuster
(with proper gearing). HD set is a true strip/street inders when used with a Ram hydraulic release RAM78300
competition clutch system that can handle the rigors bearing. The Force 9.5 and 10.5 kits include a Allows adjust-
of weekend racing and spirited street driving. zero balance 168T billet aluminum SFI certified ing clutch pedal position in virtually any
Part No. Description flywheel. 1998-14 Camaro. vehicle using an internal hydraulic slave
RAM88931HDX 2010-14 V8, HDX, 11.0" x 1-1/8", 26-Spline Part No. Description cylinder. Unit plumbs inline with the feed
RAM98931 2010-14 V8, Powergrip, 11.0" x 1-1/8", 26-Spline RAM75-2100 Force 9.5 Twin-Plate Clutch Kit, 1-1/8"-26 Input line from the slave cylinder and is compat-
RAM98931HD 2010-14 V8, HD, 11.0" x 1-1/8", 26-Spline RAM80-2100 Force 10.5 Twin-Plate Clutch Kit, 1-1/8"-26 Input
RAM88931HDX GM Camaro LS 1998-02, HDX 11.0" x 1-1/8", 26-Spline ible with all factory or aftermarket hydraulic
RAM98931HD GM Camaro LS 1998-02, HD 11.0" x 1-1/8", 26-Spline clutch release bearings.
“Smart Sleeve” Pinion Crush Sleeve RAT11007
Ratech offers a new “Smart Sleeve” technology built into this 2010-14 Camaro
pinion crush sleeve. Replace the stock crush sleeve with more precise and con-
sistent thrust pressure. Approximately half the fastener torque normally required to
compress the spacer. Cycle duty is better than a solid spacer and shim pack.

Installation Kits
Basic Kit: pinion shims, crush sleeve, pinion seal, cover gasket Housing Basic Inst. Kit Installation Kit Bearing Kit Complete Kit
Installation Kit: pinion shims, carrier shims, crush sleeve, pinion seal, pinion nut, GM 7.5", 1993-98 RAT408K RAT108K RAT228B RAT308TK
ring gear bolts, cover gasket Camaro 2010-14 — — — RAT381K
Bearing Kit: pinion and carrier bearings
Complete Set: All small parts and bearings to com plete a ring and pinion installation.
Individual Component Parts
Whether it's carrier bearings or just a pinion nut, Ratech components will complete the rear end overhaul.
Housing Pinion Shims Carrier Shims Crush Sleeve/Smart Sleeve Pinion Seal Pinion Nut Ring Gear Bolt Cover Gasket Head Bearing Tail Bearing Carrier Bearing Set
GM 7.5" 1993-98 RAT1104 RAT1105 RAT3107/RAT11003 RAT6107 RAT1501 RAT1303 RAT5110 RAT7009 RAT8001 RAT9002
GM 8.6" 2010-17 RAT1102 RAT1101 RAT3119/RAT11007 — RAT1513 RAT1303 — — — RAT9030

Ring and Pinion
10 hole housing, 1.438" diameter pinion, 27-spline. 1993-98 use installation kit RIC83-1044-1.
Part No. Description
1993-02 Camaro 7.5"
RIC49-0001-1 3.08 Ratio, 2 Series Carrier
RIC49-0044-1 3.23 Ratio, 3 Series Carrier
RIC49-0045-1 3.42 Ratio, 3 Series Carrier
RIC49-0005-1 3.42 Ratio, 2 Series Carrier
RIC49-0046-1 3.73 Ratio, 3 Series Carrier
RIC49-0007-1 3.73 Ratio, 2 Series Carrier
RIC69-0322-1 4.10 Ratio, 3 Series Carrier
RIC49-0009-1 4.10 Ratio, 2 Series Carrier
RIC69-0324-1 4.56 Ratio, 3* Series Carrier
RIC69-0326-1 4.56 Ratio, 2* Series Carrier
2010-15 Camaro SS 8.6"
RIC83-1077-1 Differential Gear Install Kit
* Special cross pin 80-0270-1 required.
2 fits 3.08 and numerically lower carrier.
3 fits 3.23 and numerically higher carrier.

CAMARO PRODUCTS 113
