Many believed that fiber lasers were only suitable for thin materials. Because of its longer wavelength, CO2 created enough kerf to allow for material removal. The fiber laser could not produce the same results or kerf with thicker materials. This problem has been solved by collimating technology, which can create a wider fiber laser-generated beam. This allows for materials separation and more room to remove thicker materials. The machine can switch between the beam widths, so it can process thinner materials with the narrower beam. This allows for faster processing of different-sized materials using the same fiber laser cutting machine.
The subject of material loading and unloading automation is well established in sheet laser cutting with a multitude of solutions and complexity. In contrast, tube laser cutting systems equipped with vertical storage systems, for tubes and section bars, capable of handling bars automatically and allowing for unmanned production changes have only been available for a few years.
Some things are extremely obvious. The size of the laser "generator," on a fiber laser, is much smaller than that of a traditional CO2 resonanceator. The fiber laser is made up of banks of diodes. Each module can hold 600 to 1,500W. Multiple modules can be spliced together in order to create the final powered-resonator. This module is typically about the same size and shape as a small filing box. Fiber-optic cable channels the light generated and amplifies it. The light is still the same quality and power when it exits the fibre-optic conduit. It is then adjusted for the type and focus of the material to be cut.
Learn how the Coherent StarCut Tube and StarFiber laser-powered cutting machines helped NPX Medical gain a competitive edge in stent manufacturing and more.
The fully-automatic solution for maximum productivity, fast production changes and high quality. Tube O Range min. 0.47" (12 mm) - max. 6" (152.4 mm)3D cutting modeFiber laser
Fabricators may think first of high speed cutting when thinking about fiber laser technology. It might be true that speed is relative when it involves tube cutting. It's about how long it takes to cut a tube to meet the specifications, not its actual speed.
Record speeds are achieved by the TruLaser Tube 5000 fiber. This fiber takes full advantage the solid-state laser's strengths. This means that the user can process quickly and have access to a large number of parts.
Lasertube can help you make improvements to parts based on your customers' needs.
PowerLine C are CO2 laser-based systems for precision drilling, cutting, scribing, marking, and engraving of many non-metals, including glass, organic materials.
Gulf States Saw & Machinery Co., Inc. offers a wide range of fabrication services, including processing tubes, structural steel, and pipes. Gulf States Saw & Machinery Co., Inc. tube-lasers offer superior laser cutting technology, and many incorporate additional processing functions to provide fabricators with added value.
Tube and sheet metal cutting by a combined laser system. Tubes up O 4.72", 120 mm. Sheets up 236". x 79". (6000mm x 2000mm).Fiber Laser
Leaders in advanced laser-cutting solutions and CNC controls.
Their high cutting efficiency is what distinguishes CO2 lasers. Their main area of use is in the medium to large range of materialthicknesses. Laser beam cutting edges excel in throughburr-free and low scoring. This means that cut parts can be further processed without the need to rework.
Another thing to consider is the modular design of the fiber laser. These modules are small enough to be carried in a briefcase and allow for redundancy. The resonator does not completely shut off if one module fails. The fiber laser acts redundantly in that it can produce more power temporarily in order to support the damaged module until repairs can take place. (This can, by the way can be done on the field). Other times, the fiber-resonator can continue producing lower power until repairs can take place. A CO2 resonator issue can lead to the complete resonator being down.
Maximum material cutting thicknesses by 1000W fiber laser cutting machine: Carbon steel has a maximum thickness of 10mm; stainless steel has a maximum thickness of 5mm; aluminum plate has a maximum thickness of 3mm; and copper plate has a maximum thickness of 3mm.
Modern CO2 machines typically generate the laser beam in a sealed glass tube filled with gas, typically carbon dioxide. A high voltage flows through the tube, interacting with the gas particles and increasing their energy, resulting in the production of light.
What is the operation of a CO2 Laser? Modern CO2 machines typically generate the laser beam in a sealed glass tube filled with gas, typically carbon dioxide. A high voltage flows through the tube, interacting with the gas particles and increasing their energy, resulting in the production of light.
