K20
Roll-out Trays
Panels-Shelving-Trays
Roll-out Tray Divided Kit Field Installation
# compartments
ROTDK12•24 •21 •18
3
ROTDK15•24 •21 •18
4
ROTDK18•24 •21 •18
5
ROTDK21•24 •21 •18
6
ROTDK24•24 •21 •18
7
ROTDK27•24 •21 •18
8
ROTDK30•24 •21 •18
9
ROTDK33•24 •21 •18
10
ROTDK36•24 •21 •18
11
• Tray is 2 1/4” high at front and 10” high at back
• Includes full extension soft-close runners
• 18”, 21” and 24” depths only
• Plywood doweled construction
• Order Example:
For B15L—order ROTDK 15•24
For B15R-RD18—order ROTDK 15•18
APC
MI
10˝
Roll-out Tray Divided Kit
Field Installation Chart
Cabinet
(Max)
#ROTDKs
Base
Base•FH
Base•FH•40
Tall
Desk
Desk•FH
Vanity
Vanity•FH
VLC 88 ½˝ H N/A (Top)
1 (Bottom)
1
1
1
1
N/A
N/A
N/A
N/A
