459 / 601
K16
Roll-out Trays
Panels-Shelving-Trays
Roll-out Trays
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
APC All Plywood Construction
MI
Matching Interior
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
DROT 12 •24
code
width
depth
Deluxe Dovetailed Roll-out Tray Factory Installed
i
1DXFWROT
i
2DXFWROT
i
3DXFWROT
i
4DXFWROT
i
5DXFWROT
i
6DXFWROT
s
1DXROT
s
2DXROT
s
3DXROT
s
4DXROT
s
5DXROT
s
6DXROT
• Roll-out Trays (ROT) are 4” deep, 3/4˝ solid
wood dovetailed sides with 3/16” plywood
bottom, notched front and full extension runners with
integrated buffer
• 18”, 21” and 24” depths only
• Shelves are eliminated when this option is selected
• Tray location is adjustable
• Order Deluxe Dovetailed Roll-out Tray (DXROT) for
cabinets that do
not
have center stiles; includes cabinets
with BUTT doors.
Order Example: B36BUTT-2XDROT; B24L-2DXROT
• Full-width trays
not
available in 39”, 42”, 45” or 48”
• Trays are
not
evenly spaced
• Order Example:
Installed—U182484L-3DXROT
Installed—B15L-2DXROT
Installed—B36-2DXFWROT
APC
MI
Available only in the width
configurations shown
i
There is no need to order Mullion Strip
Base (MSB). When Full-width Roll-out Trays
(FWROT) are ordered for 30˝, 33˝ or 36˝ wide
cabinets, the double doors will have a mullion
attached to the left door. Full-width Roll-out
Trays (FWROT)
are
not available factory
installed on Utility cabinets (U) wider
than 24˝
s
Not
available on double door cabinets with a
center stile
Deluxe Dovetailed Roll-out Tray Field Installation
DXROT12•24 •21 •18
DXROT15•24 •21 •18
DXROT18•24 •21 •18
DXROT21•24 •21 •18
DXROT24•24 •21 •18
DXROT27•24 •21 •18
DXROT30•24 •21 •18
DXROT33•24 •21 •18
DXROT36•24 •21 •18
• Roll-out Trays (ROT) are 4” deep, 3/4˝ solid wood
dovetailed sides with 3/16” plywood bottom, notched
front and full extension runners with integrated buffer
• 18”, 21” and 24” depths only
• Tray location is adjustable
• Mounting hardware and runners included
• Order Example:
For U182484—order DXROT18•24
For B15L—order DXROT15•24
For VB1518R—order DXROT15•18
For VB15L—order DXROT15•21
APC
MI
Deluxe Dovetailed Roll-out Tray
Field Installation Chart
Cabinet
(Max)
#DXROTs
Base
Base•FH
Base•FH•40
Tall
Desk
Desk•FH
Vanity
Vanity•FH
VLC 88 ½˝ H 6 (Top)
4 (Bottom)
3
4
5
10
2
3
3
4
