448 / 601
K5
Paneling
Panels-Shelving-Trays
Paneling
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
APC All Plywood Construction
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
WSK 12
30
code
width
height
Wood Veneer Paneling
Engineered Wood
Construction Code Width x Height x Thickness
u
WPL4834
48” x 34 1/2” x 3/8”
u
WPL9634
96” x 34 1/2” x 3/8”
WPL4848
48” x 48” x 3/8”
u
WPL9648
96” x 48” x 3/8”
WPL4896
48” x 96” x 3/8”
Plywood
Construction Code Width x Height x Thickness
WSK1230
11 1/4” x 30” x 3/16”
WSK2134
20 1/4” x 34 1/2” x 3/16”
WSK2434
23 1/4” x 34 1/2” x 3/16”
WSK2136
20 1/4” x 36” x 3/16”
WSK1248
11 1/4” x 48” x 3/16”
un
WSK4848
48” x 48” x 3/16”
un
WSK9648
96” x 48” x 3/16”
WSK1284
11 1/4” x 84” x 3/16”
WSK2484
23 1/4” x 84” x 3/16”
WSK3684
36” x 84” x 3/16”
WSK1287
11 1/4” x 87” x 3/16”
WSK2487
23 1/4” x 87” x 3/16”
WSK2188
20 1/4” x 88 1/2” x 3/16”
WSK1290
11 1/4˝ x 90˝ x 3/16˝
WSK2490
23 1/4˝ x 90˝ x 3/16˝
WSK1293
11 1/4˝ x 93˝ x 3/16˝
WSK2493
23 1/4˝ x 93 x 3/16˝
WSK1296
11 1/4” x 96” x 3/16”
WSK2496
23 1/4” x 96” x 3/16”
WSK3696
36” x 96” x 3/16”
WSK12108
11 1/4” x 108” x 3/16”
WSK12120
11 1/4” x 120” x 3/16”
WSK24108
23 1/4” x 108” x 3/16”
WSK24120
23 1/4” x 120” x 3/16”
WSK36108
36” x 108” x 3/16”
WSK36120
36” x 120” x 3/16”
• Painted hardwood supplied for EverCore™ and
Laminate
• Painted or Stained hardwood supplied for
Woodgrain Laminate door styles
• Finished one side only
• Edges are unfinished with no edgebanding
I
APC is optional for WPL
Remember to order “Furniture Ends”
(FPEB) or a Wood Skin (WSK) for
wall cabinets that will be at the end
of a run when applying decorative moldings.
This will result in a flush application on the
return.
Remember to order a 3/16” skin
(WSK) for the exposed ends of 93” &
96” high cabinets to conceal the
seam between the loose toe kick and the
cabinet.
Remember, the grain on paneling
normally runs along the length of
the panel. Cross grain means grain
goes with the short edge.
I
APC
Standard
Grain
Panel
Cross
Grain
Panel
u
Cross grain panel for peninsula application
n
Not
available in Sturbridge; Hayward and
Manchester supplied plain sawn
Grey color coding indicates new product, size or code.
