J6
Passport Cabinets
Passport cabinetry is available in 1/2” overlay door styles only.
Passport Cabinets
Passport Base End Corner
ABEC24
• One fixed shelf
• Can be installed on either right or left end
• Contrasting Back Options (CBEB, CPLB, CVGR)
not
available
l
PE
l
APC
APFC
FPEB
l
MI
OE
RD
IF
TWR
XS
l
GD
RTK
32 ½˝
24˝
24˝
24˝
67.5°
135°
24˝
23¾˝
18 / ˝
Passport Base End Open Shelf
Specify R or L
ABEOS1224 R or L
• One fixed shelf
• 5/8” wood veneer construction
• Painted hardwood supplied for EverCore™
• 11 5/8” radius
• 1 3/16˝ thick bottom shelf
• Toe kick is finished
• Left shown
• For Curved Moldings, see Molding section in
Decorative Enhancements
I
Reduced Depth (RD) available in 3” increments to a
minimum of 12”
PE
l
APC
APFC
FPEB
v
MI
OE
I
RD
IF
TWR
XS
GD
RTK
12
˝
24˝
12˝
11 / ˝ R
11 / ˝
10 ¼˝
32 ½˝
24˝
Passport Solid Wood Base End Open Shelf
Specify R or L
ASBEOS1224 R or L
• One fixed shelf
• 5/8˝ wood veneer on sides and back
• 1 3/16˝ thick bottom shelf
• 11 5/8” radius
• Solid wood construction on shelves only
• Painted hardwood supplied for EverCore™
• Toe kick is finished
• Left shown
• For Curved Moldings, see Molding section in
Decorative Enhancements
I
Shelves remain solid when APC option is chosen;
sides and back will be 11/16˝ matching wood veneer
plywood
I
Reduced Depth (RD) available in 3” increments to a minimum of 12”
PE
I
APC
APFC
FPEB
v
MI
OE
I
RD
IF
TWR
XS
GD
RTK
12
˝
24˝
12˝
11 / ˝ R
32 ½˝
24˝
11 / ˝
10 ¼˝
Passport Peninsula Base End Open Shelf
APBEOS2412
• Two fixed shelves
• 5/8˝ wood veneer construction; back is 11/16˝ when
APC option is chosen
• 1 3/16˝ thick top and bottom shelves
• 11 5/8” radius
• Painted hardwood supplied for EverCore™
• Toe kick is finished
• Back may be notched in field for continuous toe kick
applications
• For Curved Moldings, see Molding section in
Decorative Enhancements
PE
l
APC
APFC
FPEB
v
MI
OE
RD
IF
TWR
XS
GD
RTK
24˝
32 ½˝
10 ¼˝
10 ¼˝
12 / ˝
24˝
Passport Peninsula Solid Wood Base End Open Shelf
ASPBEOS2412
• Two fixed shelves
• 5/8˝ wood veneer on back panel
• 1 3/16˝ thick top and bottom shelves
• 11 5/8” radius
• Solid wood construction on shelves only
• Painted hardwood supplied for EverCore™
• Toe kick is finished
• Back may be notched in field for continuous toe kick
applications
• For Curved Moldings, see Molding section in
Decorative Enhancements
I
Shelves remain solid when APC option is chosen; back
will be 11/16˝ matching wood veneer plywood
PE
I
APC
APFC
FPEB
v
MI
OE
RD
IF
TWR
XS
GD
RTK
24˝
32 ½˝
10 ¼˝
10 ¼˝
12 / ˝
24˝
