J5
Passport Cabinets
Passport cabinetry is available in 1/2” overlay door styles only.
Passport Cabinets
Passport Base Dishwasher Cabinet
ABDW27
• Allows for 11” raised installation of standard dishwashers
• Finished top required
• Plywood floor
• False drawer front
l
PE
l
APC
l
APFC
l
FPEB
MI
OE
RD
IF
TWR
l
XS
GD
RTK
46 ½˝
24˝
27˝
Passport Base Blind Corner w/Pull-out
Specify R or L Blind
ABBC36 R or L•BPP
• Requires a minimum of 39” wall space
• Blind panel (stile) is 6” wide
•
Must
be pulled min. 12”, max. 15”
• Pull-out Heights:
Top shelf—8 1/4”
Bottom shelf—7 3/4”
• Right blind shown
• Filler included
• Unit slides on heavy duty full extension runners with
integrated buffer
•
Note:
If using decorative hardware on adjacent cabinets,
allow at least 40” wall space to allow for clearance of pull-
out unit
l
PE
l
APC
l
APFC
l
FPEB
l
MI
OE
RD
IF
TWR
l
XS
GD
l
RTK
32 ½˝
24˝
27˝
Passport Peninsula Base Blind Corner
APBBC27
• One adjustable shelf
• For use as a starter cabinet for peninsula
• Two 5 1/2” stiles on blind side allow cabinet to be used as
right or left
• Reversible
l
PE
l
APC
l
APFC
l
FPEB
l
MI
OE
l
RD
IF
TWR
l
XS
l
GD
RTK
APBBC27
Peninsula
Base Cabinet
5 ½˝ Stiles
Base
Cabinet
32 ½˝
27˝
24˝
24˝
27˝
Passport Peninsula Base Blind Corner w/Pull-out
APBBC36 R or L•BPP
• Requires a minimum of 39” wall space
• Blind panel (stile) is 6” wide
•
Must
be pulled min. 12”, max. 15”
• Pull-out Heights:
Top shelf—8 1/4”
Bottom shelf—7 3/4”
• Right blind shown
• Filler included
• Unit slides on heavy duty full extension runners with
integrated buffer
•
Note:
If using decorative hardware on adjacent cabinets,
allow at least 40” wall space to allow for clearance of pull-out unit
l
PE
l
APC
l
APFC
l
FPEB
l
MI
OE
RD
IF
TWR
l
XS
GD
RTK
32 ½˝
24˝
Passport Lazy Susan
ALS36
• Two pie-cut, 28” diameter, interior Viraguard rotating
shelves
• Requires 36” of wall space
• Doors are attached to and rotate with the Lazy Susan
• Contrasting Back Options (CBEB, CPLB, CVGR)
not
available
PE
l
APC
APFC
FPEB
MI
OE
RD
IF
TWR
l
XS
GD
RTK
32 ½˝
