326 / 601
FRONT VIEW
BACK VIEW
17
/ ˝
7
˝
19 / ˝ 25 / ˝
31 / ˝
TOP VIEW
C
17
/ ˝
5¼˝
A
B
19
/ ˝
25
/ ˝
31
/ ˝
3
/ ˝
3
/ ˝
1
˝
7
˝
3
˝
7
˝
4
˝
Dimension
A
Dimension
B
Dimension
C
12 / ”
15 / ”
18 / ”
CDXROT30
CDXROT36
CDXROT42
7 / ”
10 / ”
13 / ”
5 / ”
8 / ”
11 / ”
Factory Installed
1CDXROT30
1CDXROT36
1CDXROT42
Field Installed
CDXROT30
CDXROT36
CDXROT42
G5
Vanity Cabinets
Vanity Cabinets
Console Vanity
Specify R or L
Classic Leg
VCN242134 R or L•CLS
VCN302134 •CLS
VCN362134 •CLS
VCN422134 •CLS
VCN482134 •CLS
Plain Square Post
VCN242134 R or L•PSP
VCN302134 •PSP
VCN362134 •PSP
VCN422134 •PSP
VCN482134 •PSP
Roman Spindle
VCN242134 R or L•RSP
VCN302134 •RSP
VCN362134 •RSP
VCN422134 •RSP
VCN482134 •RSP
Sterling Leg
VCN242134 R or L•STL
VCN302134 •STL
VCN362134 •STL
VCN422134 •STL
VCN482134 •STL
Tapered Leg
VCN242134 R or L•TPL
VCN302134 •TPL
VCN362134 •TPL
VCN422134 •TPL
VCN482134 •TPL
• Available in full overlay door styles only
• Available in Cherry, EverCore™, High-Gloss
Laminate, Laminate, Woodgrain Laminate
and Maple door styles only
• Painted hardwood supplied for EverCore™
and Laminate
• Painted hardwood supplied for Woodgrain
Laminate door styles; only available in white
• Open area height from top of bottom shelf
to cabinet frame is 13”
• Plumbing cutout is centered; measures 4 1/4”
x 10”
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
• Console Vanity Deluxe Roll-Out Tray (CDXROT) is
available for factory or field installation in 30”, 36” and
42” VCN wide cabinets
For a finished look, we recommend attaching
replacement doors to the end panels
(RD1515NH.B — sold separately, qty. 2
needed if covering both ends)
In order to complete the furniture look on
your console vanity, limit your countertop
overhang to 1/8” on the front and both sides.
A standard size vanity countertop will work with the
console vanity, but keep in mind the countertop
overhang to the front will only be 1/8”; overhang on
the sides will be 1/2”. Be sure to account for the
positioning of the vanity bowl in relation to the
cabinet. If you use a large vanity bowl or if your bowl is
positioned too far forward, you may need to notch the
inside top rail of the frame in order to accommodate
the bowl.
PE
APC
v
APFC
FPEB
v
MI
DE
OE
RD
ID
IF
TWR
WR
XS
GD
RTK
VTK
34 ½˝
15
14
/ ˝
13
/ ˝
34 ½˝
21˝
21˝
VCN24
VCN
30-48
/ ˝
CLS
34 ½˝
RSP
34 ½˝
PSP
34 ½˝
TPL
34 ½˝
STL
34 ½˝
¾˝
Console Vanity Deluxe Roll-Out Tray
• Designed specifically for Console Vanity
(VCN) cabinets
• Full extension runner, pulls out past the face
frame
• Trays are 7” high and 17 23/32” deep
PE
APC
APFC
FPEB
MI
DE
OE
RD
ID
IF
TWR
WR
XS
GD
RTK
VTK
