322 / 601
G1
Vanity Cabinets
Vanity Cabinets
Vanity Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
PE
Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI
Matching Interior
DE Integrated Decorative End
OE Operational End
RD Reduced Depth
ID Increased Depth
IF
Inverted Frame
TWR Top Wide Rail
WR Wide Bottom Rail
XS
Extended Stile
GD Glass Doors
RTK Recessed Toe Kick
VTK Void Toe Kick
Note:
Standard vanity cabinet box depth is 18” or 21” unless stated otherwise. Add
door thickness for total depth. Standard vanity cabinet height is 34 1/2” unless
stated otherwise.
All double door cabinets will have butt doors unless stated otherwise. When BUTT
is in all capitals, it
must
be included as part of your ordering nomenclature. A (Butt)
in parentheses is for your information and isn’t required on an order form.
Material dimensions listed may vary slightly from actual dimensions of the product.
Specifications subject to change without notice.
VCD 30 18 34
code
width depth height
Wall Hung Vanity
Offset Right
12” wide left door with single shelf;
24” wide right door
WHVOR3618
WHVOR3621
Offset Left
12” wide right door with single shelf;
24” wide left door
WHVOL3618
WHVOL3621
• U-shaped Deluxe Roll-out Tray
(UDXROT) available on 24” side
(optional)
• Installation instructions included
PE
APC
v
APFC
FPEB
l
MI
DE
OE
RD
ID
IF
TWR
WR
XS
l
GD
RTK
VTK
20 ½˝
18˝ 21˝
36˝
Offset Left shown
New
Gray color coding indicates new product, size or code.
Wall Hung Vanity Full-Height Door
18” Deep
WHVC2418
WHVC3018
WHVC3618
21” Deep
WHVC2421
WHVC3021
WHVC3621
• Full-height BUTT doors
• U-shaped Deluxe Roll-out Tray
(UDXROT) available (optional)
• Installation instructions included
PE
APC
v
APFC
FPEB
l
MI
DE
OE
RD
ID
IF
TWR
WR
XS
l
GD
RTK
VTK
20 ½˝
18˝ 21˝
24˝ 30˝ 36˝
New
Gray color coding indicates new product, size or code.
Wall Hung Vanity Combination Drawer
Drawers Right
18” Deep
WHVCD4218 DR
30” left BUTT door section
WHVCD4818 DR
36” left BUTT door section
Drawers Left
18” Deep
WHVCD4218 DL
30” right BUTT door section
WHVCD4818 DL
36” right BUTT door section
Drawers Right
21” Deep
WHVCD4221 DR
30” left BUTT door section
WHVCD4821 DR
36” left BUTT door section
Drawers Left
21” Deep
WHVCD4221 DL
30” right BUTT door section
WHVCD4821 DL
36” right BUTT door section
• 12” wide drawers
• U-shaped Deluxe Roll-out Tray
(UDXROT) available (optional)
• Installation instructions included
PE
APC
v
APFC
FPEB
l
MI
DE
OE
RD
ID
IF
TWR
WR
XS
l
GD
RTK
VTK
20 ½˝
18˝ 21˝
42˝ 48˝
Drawers Right shown
New
Gray color coding indicates new product, size or code.
