Wall Cabinets
D58
Wall Hoods
Peninsula Wall Hood Classic Chimney Flat Panel Valance
• Solid wood/wood veneer construction
• Check local building codes for required
clearances between the Wall Hood and
cooking surface
• A 3˝ space is recommended on the
right and left side of this unit before
beginning the adjacent cabinet runs
• 32˝ high hoods are designed for use
with 8 foot ceilings
• 44˝ high hoods are designed for use with 9 ft.
ceilings
• 56˝ high hoods are designed for use with 10 ft.
ceilings
• Decorative molding matches Soffit Crown Molding
profile (SCM8)
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™ and
Laminate
•
Not
available in Sturbridge. Beale, Hayward and
Manchester supplied plain sawn
• 30˝ wide requires component package “K”
• 36˝–42˝ wide requires component package “H” or
“O”
•
Note
: Cabinetry and appliances located below
these Wall Hoods
must
be pulled to a minimum of
27˝deep and a maximum of 30˝ deep for improved
function
•
Note
: Wall hood
must
be securely anchored to
ceiling
PE
v
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
PWHCCFPV30
7 ⁄
˝
6 ⁄
˝
28 ⅝˝
24 ½˝
PWHCCFPV36
14 ½˝
10 ½˝
34 ⅝˝
28 ½˝
PWHCCFPV42
20 ½˝
10 ½˝
40 ⅝˝
28 ½˝
PWHCCFPV•P
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
32˝
44˝
56˝
11
15
/
16
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
32˝
44˝
56˝
11
15
/
16
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
PWHCCFPV•BE
Unless indicated, measurements include molding
Wall Hood Classic Artisan Chimney
• Solid wood/wood veneer construction
• Check local building codes for required
clearances between the Wall Hood and
cooking surface
• Will accept optional onlays, ordered
separately; see Molding Accents section
of this book
• A 3˝ space is recommended on the
right and left side of this unit before
beginning the adjacent cabinet runs
• 30 5/8˝ high hoods are designed for use
with 8 foot ceilings
• 42 5/8˝ high hoods are designed for use
with 9 ft. ceilings
• 54 5/8˝ high hoods are designed for use with 10 ft.
ceilings
• Shaded areas are unfinished surfaces that allow for
field application of paint or other decorative material
• Lower molding matches Beaded Panel Molding
(BPM8) profile, other molding matches Soffit Crown
Molding profile (SCM8)
• This product will
not
be covered under warranty once
alterations of any kind have been made
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for EverCore™ and
Laminate
•
Not
available in Sturbridge. Beale, Hayward and
Manchester supplied plain sawn
• 19˝ deep requires component package “J”
• 24˝ deep requires component package “G” or “P”
•
Note
: Cabinetry and appliances located below these
Wall Hoods
must
be pulled to a minimum of 27˝deep
and a maximum of 30˝ deep for improved function
•
Note
: Wall Hood
must
be securely anchored to wall
Select a Wall Hood Classic Artisan Chimney
when your design requires a customer
specified finish treatment such as tile, stucco,
metal or paint. The chimney and angled
sections of the hood are unfinished to allow paint or
other adhesives to hold more securely. The valance
and molding section will match the wood and finish of
your chosen door style.
PE
v
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
WHCC30•A
8˝
7 ⁄
˝
28 ½˝
18 ⁄
˝
WHCC36•A
14 ⁄
˝
10 ¾˝
34 ½˝
21 ⁄
˝
WHCC42•A
20 ½˝
10 ¾˝
40 ½˝
21 ⁄
˝
20
3
/
16
˝
23
7
/
16
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
3
/
4
˝
15
1
/
2
˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
6
5
/
16
˝
8˝, 20˝, 32˝
22
5
/
8
˝
30
5
/
8
˝
42
5
/
8
˝
54
5
/
8
˝
WHCC•A
Unless indicated, measurements include molding.
Shaded areas are unfinished.
Beaded Panel
32” High
PWHCCFPV302832 •BE
PWHCCFPV363332 •BE
PWHCCFPV423332 •BE
44” High
PWHCCFPV302844 •BE
PWHCCFPV363344 •BE
PWHCCFPV423344 •BE
56” High
PWHCCFPV302856 •BE
PWHCCFPV363356 •BE
PWHCCFPV423356 •BE
54 5/8” High
WHCC301954 •A
WHCC361954 •A
WHCC362454 •A
WHCC422454 •A
Plain
32” High
PWHCCFPV302832 •P
PWHCCFPV363332 •P
PWHCCFPV423332 •P
44” High
PWHCCFPV302844 •P
PWHCCFPV363344 •P
PWHCCFPV423344 •P
PWHCCFPV302856 •P
56” High
PWHCCFPV363356 •P
PWHCCFPV423356 •P
30 5/8” High
WHCC301930 •A
WHCC361930 •A
WHCC362430 •A
WHCC422430 •A
42 5/8” High
WHCC301942 •A
WHCC361942 •A
WHCC362442 •A
WHCC422442 •A
