Wall Cabinets
D60
Wall Hoods
Peninsula Wall Hood Classic Chimney Raised Panel Valance
Plain
32” High
PWHCCRPV302832 •P
PWHCCRPV363332 •P
PWHCCRPV423332 •P
44” High
PWHCCRPV302844 •P
PWHCCRPV363344 •P
PWHCCRPV423344 •P
56” High
PWHCCRPV302856 •P
PWHCCRPV363356 •P
PWHCCRPV423356 •P
Beaded Panel
32” High
PWHCCRPV302832 •BE
PWHCCRPV363332 •BE
PWHCCRPV423332 •BE
44” High
PWHCCRPV302844 •BE
PWHCCRPV363344 •BE
PWHCCRPV423344 •BE
56” High
PWHCCRPV302856 •BE
PWHCCRPV363356 •BE
PWHCCRPV423356 •BE
• Solid wood/wood veneer
construction
• Check local building codes
for required clearances
between the Wall Hood
and cooking surface
• A 3˝ space is recommended
on the right and left side of
this unit before beginning
the adjacent cabinet runs
• 32˝ high hoods are designed for use with
8 foot ceilings
• Decorative molding matches Soffit
Crown Molding profile (SCM8)
• Chimney section shipped separately
•
Not
designed to be used with a soffit
• Painted hardwood supplied for
EverCore™ and Laminate
•
Not
available in Sturbridge. Beale,
Hayward and Manchester supplied plain
sawn
• 30˝ wide requires component package
“K”
• 36˝–42˝ wide requires component
package “H” or “O”
•
Note
: Cabinetry and appliances located
below these Wall Hoods
must
be
pulled to a minimum of 27˝deep and
a maximum of 30˝ deep for improved
function
•
Note
: Wall hood
must
be securely
anchored to ceiling
PE
v
APC
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
Opening Sizes
Cabinet
Top Width
Top Depth BottomWidth Bottom Depth
PWHCCRPV30
7 ⁄
˝
6 ⁄
˝
28 ⅝˝
24 ½˝
PWHCCRPV36
14 ½˝
10 ½˝
34 ⅝˝
28 ½˝
PWHCCRPV42
20 ½˝
10 ½˝
40 ⅝˝
28 ½˝
WHCCRPV•P
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
15
/
16
˝, 15˝
9
3
/
16
˝
24˝
8˝, 20˝, 32˝
32˝
44˝
56˝
14
15
/
16
˝
21
1
/
2
˝
27
1
/
2
˝
28
1
/
4
˝
32
11
/
32
˝
32
1
/
4
˝
38
1
/
4
˝
44
1
/
4
˝
11
15
/
16
˝, 15˝
PWHCCRPV•BE
Unless indicated, measurements include molding
Wall Hood Box
18” High
WHB301818
WHB361818
WHB362118
WHB422118
23 1/2” High
WHB301824
WHB361824
WHB362124
WHB422124
30” High
WHB301830
WHB361830
WHB362130
WHB422130
36” High
WHB301836
WHB361836
WHB362136
WHB422136
• Solid wood/wood veneer
construction
• Laminates are painted
hardwood
• All door styles will default
to full overlay
• Doors are attached by false
front clips.
Not
operational
• Designed to align with top
of adjacent cabinets
• 30” and 36” wide hoods have a single
door panel
• 42” wide hoods have three door panels
• 19” deep requires component package “J”
• 22” deep requires component package
“G” or “P”
• Check local building codes for required
clearances between the Wall Hood and
cooking surface
• The 18” high Wall Hood Box will require
a soffit or a molding box application to
house the duct work for the blower unit
•
Not
available in Northwood Roman,
Northwood Square, Stratford Roman or
Stratford Square door styles
•
Note
: Square doors will be supplied when
ordered in arched door styles
•
Note
: Cabinetry and appliances located
below these Wall Hoods
must
be
pulled to a minimum of 27˝deep and
a maximum of 30˝ deep for improved
function
PE
APC
v
APFC
FPEB
MI
DE
RD
ID
XS
XSG
GD
WHB361824
18˝
23
½˝
30˝
36˝
18˝
23
½˝
30˝
36˝
19˝, 22˝
30˝, 36˝
42˝
22˝
WHB422124
