Wall Cabinets
D49
Wall Microwave Cabinets
Wall Microwave
Cabinets
Construction Options and
Modifications
v
Included as standard
l
Available with an upcharge
I
Available with exceptions
(Blank)
Not
available
Installation notes: Installation of a wall
cabinet 30” or wider, by itself, is
not
recommended by KraftMaid and requires
additional support, such as attachment to
a soffit, or support from below.
Any wall cabinet over 24” wide or 30”
high with a depth greater than 12” or
butt doors
must
be installed between two
cabinets, a cabinet and a wall, or supported
from below.
Material dimensions may vary slightly
based on lumber industry standards.
Specifications subject to change without
notice.
PE Plywood Ends
APC All Plywood Construction
APFC All Plywood Furniture Construction
FPEB Furniture Plywood Ends
MI Matching Interior
RD Reduced Depth
ID Increased Depth
XS Extended Stile
GD Glass Doors
WMC 30 18 36
code
width
depth
height
Wall Microwave Cabinet 36˝ H
Opening trimmable to:
Width: 16” to 25”
Height: 13” to 19”
WMC271836 (Butt)
WMC272136 (Butt)
WMC272436 (Butt)
Opening trimmable to:
Width: 19” to 28”
Height: 13” to 19”
WMC301836
WMC302136
WMC302436
• Designed for “built-in” style microwaves
•
Note
:
Must
be installed between two
cabinets or cabinet and wall with supplied
connectors
Installation of a wall cabinet 30” or
wider, by itself, is
not
recommended by KraftMaid and
requires additional support, such as
attachment to a soffit or support from below
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
ID
l
XS
l
GD
15˝
21˝
36˝
18˝, 21˝, 24˝
Wall Microwave Cabinet 36˝ H–Extended Opening
Opening trimmable to:
Width: 16” to 25”
Height: 16” to 22”
WMCE272136 (Butt)
WMCE272436 (Butt)
Opening trimmable to:
Width: 19” to 28”
Height: 16” to 22”
WMCE302136
WMCE302436
• Designed for “built-in” style microwaves
•
Note
:
Must
be installed between two
cabinets or cabinet and wall with supplied
connectors
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
RD
ID
l
XS
l
GD
12˝
24˝
36˝
21˝, 24˝
