Tall Cabinets
F1
Tall Cabinets
Tall Cabinets
Construction Options and
Modifications
I
Available with exceptions
l
Available with an upcharge
v
Included as standard
(Blank)
Not
Available
PE Plywood Ends
APC All Plywood Construction
RD9 Reduce Depth 9”
RD12 Reduce Depth 12”
RD15 Reduce Depth 15”
RD18 Reduce Depth 18”
RD21 Reduce Depth 21”
CFO Cabinet Front Only
U 15 12 84 R
code
width
depth height
hinge
Utility Cabinets 12” Deep
Specify R or L
84” High
U151284 R or L
U181284 R or L
U241284 R or L
U241284 BUTT
U301284 BUTT
U361284 BUTT
90” High
U151290 R or L
U181290 R or L
U241290 R or L
U241290 BUTT
U301290 BUTT
U361290 BUTT
Specify R or L
93” High
U151293 R or L
U181293 R or L
U241293 R or L
U241293 BUTT
U301293 BUTT
U361293 BUTT
96” High
U151296 R or L
U181296 R or L
U241296 R or L
U241296 BUTT
U301296 BUTT
U361296 BUTT
• Fixed shelf between top and bottom
section with adjustable shelves in top
section: 84” high-no shelves; 90” and 93”
high-1 shelf; 96” high-2 shelves
• If arch configuration is required for upper
door(s), please specify
• Tall doors are two-piece panel
construction except Frontier
• Frontier tall doors have a single raised panel profile
• 30” and 36” wide cabinets have 3” wide center stile in
upper section only
• Interior height of tall section on 84”, 93” and 96” tall
cabinets is 60 15/16”; 90” tall is 61 7/16”
• 93” and 96” tall cabinets include toe kick platform,
shipped unattached
• Toe Kick cover required on exposed sides of toe kick
platform
• End panels of bottom section are pre-drilled for optional
shelves
•
Note
: Shelf Kit (SK)
must
be ordered separately; see
Shelving section of this book
l
PE
l
APC
l
RD9
RD12
RD15
RD18
RD21
l
CFO
12˝
84˝
90˝
93˝
96˝
12˝
84˝
90˝
93˝
96˝
U15-U24
U24BUTT-
U36BUTT
Note
: Standard tall cabinet box depth is 12” or 24” unless stated otherwise. Add door thickness with
bumpers for total depth.
When BUTT is in all capitals, it
must
be included as part of your ordering nomenclature. A (Butt) in
parentheses is for your information and isn’t required on an order form.
Material dimensions may vary slightly based on lumber industry standards.
Specifications subject to change without notice.
