Tall Cabinets
F2
Tall Cabinets
Utility Cabinets 24” Deep
Specify R or L
84” H
U152484 R or L
U182484 R or L
U242484 R or L
U242484 BUTT
U302484 BUTT
U362484 BUTT
90” High
U152490 R or L
U182490 R or L
U242490 R or L
U242490 BUTT
U302490 BUTT
U362490 BUTT
Specify R or L
93” High
U152493 R or L
U182493 R or L
U242493 R or L
U242493 BUTT
U302493 BUTT
U362493 BUTT
96” High
U152496 R or L
U182496 R or L
U242496 R or L
U242496 BUTT
U302496 BUTT
U362496 BUTT
• Fixed shelf between top and bottom
section with adjustable shelves in top
section: 84” high-no shelves; 90” and 93”
high-1 shelf; 96” high-2 shelves
• If arch configuration is required for upper
door(s), please specify
• Tall doors are two-piece panel
construction, except Frontier which has a single raised
panel
• 30” and 36” wide cabinets have 3” wide center stile in
upper section only
• Interior height of tall section on 84”, 93” and 96” tall
cabinets is 60 15/16”; 90” tall is 61 7/16”
• 93” and 96” tall cabinets include toe kick platform,
shipped unattached
• Toe Kick cover required on exposed sides of toe kick
platform
• End panels of bottom section are pre-drilled for
optional shelves and Roll-out Trays (ROT)
• Accessory Roll-out Trays (ROT)
not
available when
cabinet is reduced to 15” depth
•
Note
: Shelf Kit (SK)
must
be ordered separately; see
Shelving section of this book
l
PE
l
APC
l
RD9
l
RD12
l
RD15
l
RD18
l
RD21
l
CFO
24˝
84˝
90˝
93˝
96˝
24˝
84˝
90˝
93˝
96˝
U15-U24
U24BUTT-
U36BUTT
Pantry Cabinet
PC362484 BUTT
PC362490 BUTT
PC362493 BUTT
PC362496 BUTT
• Fixed shelf between top and bottom
section with adjustable shelves in top
section: 84” high-no shelves; 90” and 93”
high-1 shelf; 96” high-2 shelves
• 3” wide center stile in upper section only
• 93” and 96” tall cabinets include toe kick
platform, shipped unattached
• Toe Kick cover required on exposed sides of toe kick
platform
• If arch configuration is required for upper door(s),
please specify
• Tall doors are pre-drilled for Door Pantry Rack (DPR18)
• Full overlay doors require special hardware for Door
Pantry Rack (DPR) installation; included with kit
• Tall doors are two-piece panel construction except
Frontier which has a single raised panel
• 1” thick center partition runs full height in bottom
section
• End panels and center partition in bottom section
are pre-drilled for half-depth adjustable shelves (
not
included)
• Will
not
accept Roll-out Trays (ROT)
• Pantry Cabinet can be installed next to a wall or
refrigerator. Optional interior racks will function if door
opening is restricted to no less than 90°
• Reinforced cabinet bottom
l
PE
l
APC
RD9
RD12
RD15
RD18
RD21
l
CFO
84˝
90˝
93˝
96˝
24˝
PCSK3612
PCSK3612
SPR
SPR
DPR18
DPR18
36˝
24˝
Pantry Cabinet Accessory Configuration
