Base Cabinets
E16
Base Appliance Cabinets
Base Appliance
Cabinets
Construction Options and
Modifications
I
Available with exceptions
l
Available with an upcharge
v
Included as standard
(Blank)
Not
Available
When BUTT is in all capitals, it
must
be included
as part of your ordering nomenclature. A (Butt) in
parentheses is for your information and isn’t required
on an order form.
Material dimensions may vary slightly based on
lumber industry standards.
Specifications subject to change without notice.
PE Plywood Ends
APC All Plywood Construction
RD21 Reduce Depth 21”
CFO Cabinet Front Only
BMC 30 24 34
code
width
depth
height
Base Oven Cabinet Universal
BOCU30
BOCU33
• Designed for under counter mounting of
single built-in ovens
• No back panel allowing full access to electrical
connections
• Includes an adjustable oven platform supported with
heavy-duty metal mounting brackets and screws which
install into pre-drilled end panel holes at the four
corners
• 1/2” end panels
• 3” wide trimmable vertical stiles provide oven opening
width adjustment
• 10” high trimmable horizontal rail along the bottom
provides opening height adjustment. May be trimmed
to 1 1/2”
•
Not
available in Hickory
l
PE
l
APC
RD21
CFO
Opening Sizes
Cabinet Minimum Opening *Maximum Opening
BOCU30
BOCU33
* Bottom rail trimmed to 1 ½˝ high and top rail removed
24˝ wide x 18 ½˝ high
27˝ wide x 18 ½˝ high 31˝ wide x 28½˝ high
28˝ wide x 28 ½˝ high
34 ½˝
24˝
Drop-In Range Panel
DIP30
• 3/4” thick solid wood panel
• Matching front panel may be trimmed to
fit drop-in range
•
Must
be installed between two base cabinets
• Toe Kick Backer included, shipped unattached
• Matching Toe Kick cover (MTK) is required
• Field trim as needed
PE
APC
RD21
CFO
30˝
10˝
¾˝
