Base Cabinets
E15
Base Cabinets
Removable Sink Front
One Drawer Front
RSF30 BUTT
RSF33 BUTT
RSF36 BUTT
Two Drawer Fronts
RSF42
• Designed for easy field conversion from a standard sink
base functionality to access open space
• Permanently installed countertop support rail is
6-1/2” high x 3/4” thick solid wood with a factory
installed standard height matching false drawer front(s)
providing a seamless sink base appearance. (1) full-
width drawer front on 30”, 33” and 36” widths; (2) false
drawer fronts on 42” wide
• If a shorter countertop support is required when used
for universal access as additional vertical clearance, a 3”
filler can be used in place of the 6 1/2” high support rail.
Order separately
• 3/4” thick removable plywood bottom panel with
support hardware / leveling legs and a removable
clipped-on toeboard provided
• Matching solid wood baseboard provided for bottom
panel support along the kitchen wall
• Frame, doors, floor bottom and toeboard can be flat packed for easy
storage in a minimum amount of space
• Frame attached to bottom panel using quick connect (cam-locks)
fasteners providing a solid tight joint
• Some field assembly required; instructions and hardware included
• Doors and frame are shipped pre-assembled
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
CFO
34 ½˝
24˝
Universal Access Panel
UAP30
UAP33
UAP36
UAP42
• Designed for optional use with RSF and URSF
• Conceals/protects drain and water lines
• Includes one 9” and one 15” high, 3/4” thick laminate
plywood panel
• Panels are held with hidden spring clips, removable
without tools for easy access to plumbing
•
Must
be trimmed when Wood Veneer Paneling (WSK)
is used on adjacent cabinets
• Installation instructions and mounting hardware
included
PE
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
CFO
