Base Cabinets
E9
Base Cabinets
Base Combination Drawer (4) w/Two Full-Width Trays
Specify DR or DL
BCD24 DR or DL•4D•2FWT
BCD30 DR or DL•4D•2FWT
BCD36 DR or DL•4D•2FWT
• Three standard height drawers; top drawer
is full-width
• One deep drawer
• Two Full-width Roll-out Trays (FWROT)
• Specify DL (Drawer Left) or DR (Drawer
Right) position for drawers
l
PE
l
APC
RD12
RD15
l
RD18
l
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
CFO
24˝
34 ½˝
Base Combination Drawer (4) w/Two Deep Full-Width Trays
Specify DR or DL
BCD24 DR or DL•4D•2DFWT
BCD30 DR or DL•4D•2DFWT
BCD36 DR or DL•4D•2DFWT
• Three standard height drawers; top drawer
is full-width
• One deep drawer
• Two Deep Full-width Roll-out Trays
(DFWROT)
• Specify DL (Drawer Left) or DR (Drawer
Right) position for drawers
l
PE
l
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
CFO
24˝
34 ½˝
Base Pots and Pans Storage Two Drawer
BPPS27 •2
BPPS30 •2
BPPS33 •2
BPPS36 •2
• Two solid wood deep drawers
• Heavy duty full extension undermount
guides
• 3 3/16” wide full-width support cross rail
across top front of cabinet
• Drawer interior height is 8 5/8”
l
PE
l
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
l
CFO
24˝
34 ½˝
Base Three Drawer
BD12 •3
BD15 •3
BD18 •3
BD21 •3
BD24 •3
BD27 •3
BD30 •3
BD33 •3
BD36 •3
• One standard height drawer
• Two deep drawers
• Full-extension undermount soft-close
slides on all three drawers
l
PE
l
APC
RD12
RD15
l
RD18
l
RD21
1ROT
2ROT
3ROT
4ROT
6ROT
1FWROT
2FWROT
2DROT
4DROT
6DROT
2DFWROT
l
CFO
24˝
34 ½˝
