Base Cabinets
E21
Base Corner Cabinets
Lazy Susan
Specify R or L
LS33 R or L
LS36 R or L
• Two 28” diameter high impact, pie-cut
revolving white plastic shelves
• Shelves rotate independently of doors and
each other
• Shelf load rating of 15 lbs. per square foot,
not
to exceed 50 lbs.
• Two piece bi-fold door with independent
adjustment
• 168° opening hinges on face frame door
• Full Overlay door style face frame stiles
are notched to accept door hinges. Door
hinging
cannot
be inverted in field
I
Note
: Back panel (barrel) will
not
be plywood when
APC is ordered
Caution
: If cabinet is installed next to an
appliance deeper than 25”, it may interfere
with the cabinet door opening. Options
available: A) Use a filler between cabinet and appliance,
B) Pull cabinet even with appliance front, which will
result in a deeper countertop and overall base cabinet
depth dimension
PE
I
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
1FWROT
2FWROT
2DROT
2DFWROT
l
CFO
34 ½˝
24˝
24˝
10 / ˝
9˝
24˝
9˝
24˝
33˝
33˝
3˝
3˝
28˝
shelf
diameter
LS33
14 / ˝
12˝
24˝
12˝
24˝
36˝
36˝
6˝
6˝
28˝
shelf
diameter
LS36
Wood Lazy Susan
• Two 32” diameter pie-cut revolving wood
shelves
• Shelves rotate independently of doors and
each other
• Shelf height
cannot
be adjusted
• Shelf load rating of 15 lbs. per square foot,
not
to exceed 50 lbs.
• Two piece bi-fold door with independent
adjustment
• 33” minimum doorway clearance
suggested for delivery
• 168° opening hinges on face frame door
• Full Overlay door style face frame stiles are notched to
accept door hinges. Door hinging
cannot
be inverted in
field
I
Note
: Back panel (barrel) will
not
be plywood when APC
is ordered
Caution
: If cabinet is installed next to an
appliance deeper than 25”, it may interfere
with the cabinet door opening. Options
available: A) Use a filler between cabinet and appliance,
B) Pull cabinet even with appliance front, which will
result in a deeper countertop and overall base cabinet
depth dimension
PE
I
APC
RD12
RD15
RD18
RD21
1ROT
2ROT
1FWROT
2FWROT
2DROT
2DFWROT
l
CFO
34 ½˝
24˝
24˝
9
/
˝
12˝
24˝
12˝
24˝
36˝
36˝
2 / ˝
32˝
shelf
diameter
2 / ˝
Specify R or L
LS36 R or L•WLS
