K6
Decorative Appliance Panels
Panels-Shelving-Trays
Decorative Panel–Back Panel
APWSK
• Approximately 3/16˝ thick
• Back Panels will match the wood species and the color of the
selected door style and finish and can be used with or without
onlay panels to decorate any appliance
• Wood veneer engineered wood
• Finished one side only
• Quartersawn oak door styles are quartersawn wood veneer
• Plain sawn material supplied for Barnet Crafted door styles
• Painted or Stained hardwood supplied for Woodgrain Laminate
door styles
• Edges are unfinished with no edgebanding
• Painted hardwood supplied for EverCore™ and Laminate door
styles. A matching matte panel will be supplied when ordered in
High-Gloss Laminate door styles
Back Panel
MinimumWidth
”
MaximumWidth 48”
Minimum Heigh ”
Maximum Height
96”
48˝
96˝
3/4˝
4 1/2”
Minimu i
Maximu i t
Minim
i t
axi
i
Decorative Panel–Door Onlay Panel and Hinge Doors
APDRL •B or W
APDRR •B or W
APDRNH •B or W
• Doors and onlay panels ordered 10˝–55˝ high will have a single
center panel
• Doors and onlay panels ordered 55 1/16” – 80” will have a double
center panel (a horizontal center rail will equally divide the onlay
panel)
• Mitered door styles will have a single center panel, regardless of
height
• When an arched door style is selected, you
must
select Arched
(•W) or Square (•B) to determine the door and onlay panel’s top
profile
• When a square door style is selected, the square profile will be
supplied for all onlay panels as standard. It is recommended to use
a square profile when ordering an onlay panel for a dishwasher or
trash compactor application.
• Multiple doors and panels of identical size may be ordered by
listing the quantity needed. The quantity will default to one if a
number is
not
given.
• Veneer raised panel door styles will be supplied with a solid wood
center panel machined to resemble the veneer center panel
• Due to varying dimensions and designs of raised center panels,
recessed center panels may be supplied when the center panel
width or height is less than 3 1/4”
• Hinging for doors:
Doors 10” to 36” get two hinge holes
Doors 36 1/6” to 48” get three hinge holes
Doors 48 1/2” to 80” get four hinge holes
• Backs are finished
• Not
e
: Check appliance manufacturer’s specs for any additional
material (shims, spacers, etc.) that may be needed before placing
any order. Appliance model numbers are
not
sufficient, numeric
dimensions
must
be used when ordering.
10˝- 55˝
High
Mitered
Onlay Panel
8˝
36˝
10˝
80˝
55 / ˝ 80˝
High
Minimum Width
Maximum Width
Minimum Height
Maximum Height*
*Maximum height for
Woodgrain Laminate
mitered doors is 55 5/8”
