F3
Tall Cabinets
Note
: Remember to remove the white plastic “feet” from the bottom of all tall cabinets before
installation. Their sole purpose is to protect the floor after the cabinets are unboxed. Leaving them on
will result in uneven installation.
Tall Cabinets
Utility Cabinets 60 1/2” High 24” Deep
Specify R or L
Single Door
im
U92460 R or L
U122460 R or L
U152460 R or L
U182460 R or L
U212460 R or L
U242460 R or L
Double Door
m
U242460 BUTT
U272460 (Butt)
u
U302460
U302460 BUTT
u
U332460
U332460 BUTT
u
U362460
U362460 BUTT
• No shelf
• Shelf Kit (SK)
must
be ordered separately; see Shelving
section of this book
• All door styles furnished square
• No center rail on tall door for Argonne, Astoria,
Avery, Barnet, Camby, Chadwick, Cornell, Courtney,
Evana, Evana Cathedral, Ferguson, Garrison, Halden,
Harrington, Jamison, Judson, Kendrick, Layden,
Lockeford, Maxton, Northwicke, Parker House,
Rutherford, Shepparton, Sheridan, Sydney, Tennyson
and Vanderbilt door styles
• Factory installed Roll-out Trays (ROT) are
not
available
on Utility Cabinets wider than 24˝
I
Maximum Increased Depth (ID) is 27”
I
Operational End (OE) is
not
available with Increased
Depth (ID) or Reduced Depth (RD) options
Remember to attach a Mullion Strip Utility
Bottom (MSUB) to tall cabinets 30” or wider
when planning to field install roll-out trays.
This will remove the center stile and replace
it with a mullion strip on the left door.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
l
OE
I
CW
I
RD
I
ID
CH
IF
l
WR
l
XS
GD
l
RTK
l
VTK
60
1
/
2
˝
24˝
i
Harlowe, Smithton and Vanderbilt doors will have
a solid, recessed flat panel.
m
Change Width (CW) option
not
available
u
3” center stile
Utility Stack Cabinets 12” Deep
Specify R or L
84” High
im;
UST91284 R or L
UST121284 R or L
UST151284 R or L
UST181284 R or L
UST211284 R or L
UST241284 R or L
m
UST241284 BUTT
UST271284 (Butt)
UST301284 BUTT
UST331284 BUTT
UST361284 BUTT
87” High
im;
UST91287 R or L
UST121287 R or L
UST151287 R or L
UST181287 R or L
UST211287 R or L
UST241287 R or L
m
UST241287 BUTT
UST271287 (Butt)
UST301287 BUTT
UST331287 BUTT
UST361287 BUTT
90” High
im;
UST91290 R or L
UST121290 R or L
UST151290 R or L
UST181290 R or L
UST211290 R or L
UST241290 R or L
m
UST241290 BUTT
UST271290 (Butt)
UST301290 BUTT
UST331290 BUTT
UST361290 BUTT
93” High
im;
UST91293 R or L
UST121293 R or L
UST151293 R or L
UST181293 R or L
UST211293 R or L
UST241293 R or L
m
UST241293 BUTT
UST271293 (Butt)
UST301293 BUTT
UST331293 BUTT
UST361293 BUTT
96” High
im;
UST91296 R or L
UST121296 R or L
UST151296 R or L
UST181296 R or L
UST211296 R or L
UST241296 R or L
m
UST241296 BUTT
UST271296 (Butt)
UST301296 BUTT
UST331296 BUTT
UST361296 BUTT
• Includes adjustable shelves in upper section: 84” &
87” high—one shelf; 90” & 93” high—two shelves; 96”
high—three shelves
• Factory installed Roll-out Trays (ROT) are
not
available
on Utility Cabinets wider than 24˝
• Toe kick is shipped separately on 93˝ & 96˝ high
cabinets
I
Wide Bottom Rail (WR) and Recessed Toe Kick (RTK)
not
available on 93” & 96” high cabinets
I
Void Toe Kick (VTK) is
not
available on 93” and 96”
high cabinets
I
Glass doors available for top doors only
I
Change Height (CH) modifications will be made in the
upper section
I
Maximum Increased Depth (ID) is 23 15/16”
I
Operational End (OE) is
not
available with Reduced Depth (RD)
options
•
Note
: Shelf Kits (SK) for center and bottom sections
must
be
ordered separately; see Shelving section of this book
Remember to order a 3/16” skin (WSK) for the exposed
ends of 93” & 96” high cabinets to conceal the seam
between the loose toe kick and the cabinet.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
l
DE
I
OE
I
CW
l
RD
I
ID
I
CH
IF
I
WR
l
XS
I
GD
I
RTK
I
VTK
23 ½˝
27˝
30˝
33˝
36˝
23 ½˝
27˝
30˝
33˝
36˝
84˝
87˝
90˝
93˝
96˝
84˝
87˝
90˝
93˝
96˝
12˝
12˝
U24 BUTT-
U36 BUTT
U9-U24
26˝
30˝
26˝
30˝
New
i
Doors are square except full overlay arch door styles.
Laminate door styles will always be square. Harlowe,
Smithton and Vanderbilt doors will have a solid,
recessed flat panel.
m
Change Width (CW) option
not
available
;
Glass door option
not
available
Grey color coding indicates new product, size or code.
