2016 Dealer Spec Book - page 231

34 ½˝
12˝, 15˝, 18˝
12˝
15˝
18˝
24˝
38¼˝
BCSS_LR shown
10 / ˝
22 ¾˝ 24 / ˝
12 / ˝
29 / ˝
34 ½˝
38 / ˝
20 / ˝
8 / ˝ 22 ¾˝
24 / ˝
34 ½˝
34 ½˝
31 / ˝
17 ½˝
21 ½˝
10 ½˝
BCD3D
34 ½˝
BCD2D
E29 Base Corner Cabinets
Base Cabinets
Base Corner Drawer Cabinet
Two Drawer
BCD36 •2D
Three Drawer
BCD36 •3D
• 90 degree frame
• Drawer is the same as a B12
• Not available with any drawer box
accessories
• Requires 36” of wall space
l PE
l APC
APFC
FPEB
MI
DE
CW
RD
CH
TWR
l WR
l XS
GD
RTK
RTKP
l VTK
New
Grey color coding indicates new product, size or code.
Base Corner Smart Space Cabinet
Specify RR or RL
Right
m BCSS12 RR or RL
m BCSS15 RR or RL
m BCSS18 RR or RL
Specify LR or LL
Left
r BCSS12 LR or LL
r BCSS15 LR or LL
r BCSS18 LR or LL
• Roll-out Trays (ROT) are not available
• Right cabinets: Place on the left side
of a Base Corner Drawer cabinet (See
Base Corner Drawer Cabinet and Base
Corner Smart Space Companion View)
• Left cabinets: Place on the right side
of a Base Corner Drawer cabinet (See
Base Corner Drawer Cabinet and Base
Corner Smart Space Companion View)
I Furniture Ends will be supplied on the
non-angled end panels only
l PE
l APC
I APFC
I FPEB
l MI
l DE
CW
RD
CH
l TWR
l WR
I XS
l GD
l RTK
RTKP
l VTK
New
m Extended Stile (XS) available on the left side only
r Extended Stile (XS) available on the right side only
Grey color coding indicates new product, size or code.
135° Base Inside Angle Corner Cabinet
BIAC21 • Backs of cabinets are slightly recessed
to allow for wall imperfections,
shimming is required
• One adjustable shelf
l PE
l APC
l APFC
l FPEB
l MI
DE
CW
RD
l CH
TWR
l WR
l XS
GD
l RTK
RTKP
l VTK
New
Grey color coding indicates new product, size or code.
135° Base Outside Angle Corner Cabinet
BOAC6 • Backs of cabinets are slightly recessed
to allow for wall imperfections,
shimming is required
• One adjustable shelf
l PE
l APC
l APFC
l FPEB
l MI
DE
CW
RD
l CH
TWR
l WR
l XS
l GD
l RTK
RTKP
l VTK
New
Grey color coding indicates new product, size or code.
