E25
Base Corner Cabinets
Base Cabinets
Base Blind Corner w/Wood Swing-out
Specify R or L
BBC42 R or L•PSO
BBC45 R or L•PSO
BBC48 R or L•PSO
• Blind panel (stile) is 8” wide
• Blind opening is covered with an unfinished panel
• R or L indicates blind
• Door is hinged from blind panel
• Filler included
• Overlay Panel for Base Blind Corner (OPWBC)
must
be ordered separately
• One standard drawer
• Two adjustable High Back Roll-out Trays (HBROT)
• Solid wood swing-out caddy
•
Note:
Swing-out will
not
fully open if a wall, another
cabinet, appliance or any other obstruction deeper
than 24” is next to swing-out side end panel
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
CH
TWR
l
WR
l
XS
l
GD
l
RTK
l
RTKP
l
VTK
34
1
/
2
˝
24˝
Right Blind Shown
Peninsula Base Blind Corner
Specify R or L
i
PBBC36 R or L
PBBC39 R or L
PBBC42 R or L
PBBC45 R or L
PBBC48 R or L
• Blind panel (stile) is 8” wide
• Blind opening is covered with an unfinished panel
• R or L indicates blind
• Kitchen door is hinged from blind panel
• Overlay Panel for Base Blind Corner (OPWBC)
must
be ordered separately
• Single door and working drawer on kitchen side;
double doors and single drawer on peninsula side
• One adjustable shelf
• Factory installed Roll-out Trays (ROT) are
not
available
•
Note:
Two 3” base fillers included. Blind Corner
Overlay
must
be ordered separately; see Base
Accessories section of this book
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
l
RD
l
CH
TWR
l
WR
l
XS
l
GD
l
RTK
v
RTKP
l
VTK
34
1
/
2
˝
24˝
Right Blind Shown
i
Full-height, kitchen side only.
Harlowe, Smithton and Vanderbilt
doors will have a solid, recessed flat
panel.
Peninsula Base Blind Corner–27” Wide
PBBC27
• One adjustable shelf
• Two 5 1/2” stiles on blind side allow cabinet to be
used as right or left
• Double doors and single drawer
• Reversible
• For use as a starter cabinet for peninsula
• Designed to fit flush against wall, cabinet may
be pulled approximately 2 1/4”. Full overlay door
styles require a pull of at least 1” from wall to allow
decorative hardware clearance
• Filler included
• Overlay Panel for Base Blind Corner (OPWBC)
must
be ordered separately
• Working drawer and doors open to same side
Remember, when using a 27” wide Peninsula
Base Blind Corner cabinet (PBBC27), it is
highly recommended to use peninsula
cabinets on the adjacent run due to depth continuity.
If regular base cabinets are used, the run will
not
be
flush once the matching panel is applied.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
l
RD
l
CH
TWR
l
WR
l
XS
l
GD
l
RTK
v
RTKP
l
VTK
34
1
/
2
˝
24˝
5
1
/
2
˝
5
1
/
2
˝
PBBC27
Peninsula
Base
Cabinet
27˝
24˝
24˝
5 ½˝Stiles
Base
Cabinet
