E27
Base Corner Cabinets
Base Cabinets
Base Angle Full-Height Door
Specify R or L
BA36 R or L•FH
• One fixed shelf
• Angled back provides clearance for
installation
• 30 1/2˝ door clearance recommended for
delivery
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
Full overlay doors on cabinets with
an angled front are intentionally
narrower to allow proper clearance
of adjacent cabinets.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
l
CH
l
TWR
l
WR
XS
l
GD
l
RTK
RTKP
l
VTK
Wood Lazy Susan Angle
Specify R or L
LSA36 R or L•WLS
• Two 28˝ diameter rotating shelves
• Rotating shelves have plywood floor and
solid wood trim
• Shelves rotate independently
• Angled back provides clearance for
installation
• 30 1/2˝ door clearance recommended for
delivery
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
•
Note:
Full overlay door styles use a 1/2”
overlay hinge
Do
not
design a corner cabinet
adjacent to an object deeper than
the end panel. The door of the
corner cabinet may
not
function properly.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
l
CH
TWR
l
WR
XS
l
GD
l
RTK
RTKP
l
VTK
Base Drawer Angle
BDA40 •3
BDA40 •4
• Deep drawers will accept optional Bread Box
(BB)
• Angled frame designed for diagonal corner
installation only
• Requires 40 3/32˝ of wall space
l
PE
l
APC
l
APFC
l
FPEB
MI
DE
CW
RD
CH
l
TWR
WR
XS
GD
RTK
RTKP
l
VTK
Easy Reach
Specify R or L
Iu
EZR33 R or L
EZR36 R or L
• One fixed shelf
• Frame opening, from left to right edge is
10 1/2˝ for EZR33 and 14 3/4˝ for EZR36
• Face frame is scooped for hinge installation
on full overlay door styles
• Doors are profiled on one long and two short
edges and are connected with hinges
• Angled back provides clearance for
installation
• 29˝ door clearance recommended for
delivery
• Back Options (BEB and VGRB)
not
available
• Contrasting Back Options (CBEB, CPLB,
CVGR)
not
available
I
Not
available with Aluminum Frame Glass
doors
•
Note:
Does
not
include Soft-Close feature
Do
not
put an appliance next to an
Easy Reach (EZR) cabinet without
providing proper clearance for the
door to operate. Also, the cabinet
door should be hinged opposite the appliance.
l
PE
l
APC
l
APFC
l
FPEB
l
MI
DE
CW
RD
l
CH
TWR
l
WR
l
XS
I
GD
l
RTK
RTKP
l
VTK
I
Glass door option
not
available
u
Harlowe, Smithton and Vanderbilt doors will
have a solid, recessed flat panel. Courtney
doors will have a veneer, recessed flat panel.
